Danfoss FC 300

FC 300 Operating Instructions
How to Programme
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
3-7* Ramp 4
3-70 Ramp 4 Type [0] Linea r All set-ups TRUE - Uint8
3-71 Ramp 4 Ramp up Time SR All set-ups TRUE -2 Uint32
3-72 Ramp 4 Ramp Down Time SR All set-ups TRUE -2 U int32
3-75
Ramp 4 S-ramp Ratio at Accel.
Start 50 % All set-ups TRUE 0 Uint8
3-76 Ramp 4 S-ramp Ratio at Accel. E nd 50 % All set-ups TRUE 0 Uint8
3-77
Ramp 4 S -ramp Ratio at Decel.
Start 50 % All set-ups TRUE 0 Uint8
3-78 Ramp 4 S-ramp Ratio at Decel. End 50 % All set-ups TRUE 0 Uint8
3-8* O the r Ramps
3-80 Jog Ramp Time SR All set-ups TRUE -2 Uint32
3-81 Quick Stop Ramp Time SR 2 set-ups TRUE -2 Uint32
3-9* Digital Pot.Meter
3-90 Step Size 0.10 % All set-ups TRUE -2 U int16
3-91 Ramp Time 1.00 s All set-ups TRUE -2 U int32
3-92 Power Restore [0] Off All set-ups TRUE - Uint8
3-93 Maximum Limit 100 % All set-ups TRUE 0 Int16
3-94 Minimum Limit -100 % All set-ups TRUE 0 Int16
3-95 Ramp Delay 1.000 N/A All set-ups TRUE -3 TimD
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
46
MG.33.A7.02 - VLT is a registered Danfoss trademark
