FC 300 Operating Instructions
How to Programme
" 4-** Limits / Warnings
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
4-1* Motor Limits
4-10 Motor Speed Direction - All set-ups FALSE - Uint8
4-11 Motor Speed Low Limit [RPM] SR All set-ups TRUE 67 Uint16
4-12 Motor Speed Low Limit [Hz] SR All set-ups TRUE -1 Uint16
4-13 Motor Speed High Limit [RPM] SR All set-ups TRUE 67 Uint16
4-14 Motor Speed High Limit [Hz] SR All set-ups TRUE -1 Uint16
4-16 Torque Limit Motor Mode 160.0 % All set-ups TRUE -1 Uint16
4-17 Torque Limit Generator Mode 100.0 % All set-ups TRUE -1 Uint16
4-18 Current Limit ExpressionLimitSR All set-ups TRUE -1 Uint32
4-19 Max Output Frequency 132.0 Hz All set-ups FAL SE -1 U int16
4-2* Limit Factors
4-20 Torque Limit Factor Source [0] No function All set-ups TRUE - Uint8
4-21 Speed Limit Factor Sou rce [0] No function All set-ups TRUE - Uint8
4-3* Motor Fb Monitor
4-30 Motor Fe edback Loss Function [2] Trip All set-ups TRUE - Uint8
4-31 Motor Feedback Speed E rror 300 RPM All set-ups TRUE 67 Uint16
4-32 Motor Feedback Loss Timeout 0.05 s All set-ups TRUE -2 Uint16
4-5* Adj. Warnings
4-50 Wa rning Curren t Low 0.00 A All set-ups TRU E -2 Uint32
4-51 Warning Current High ImaxVLT All set-ups TRUE -2 Uint32
4-52 Warning Speed Low 0 RPM All set-ups TRUE 67 Uint16
4-53 Warning Speed High (P413) All set-ups TRUE 67 Uint16
4-54 Warning Reference Low -999999.999 All set-ups TRUE -3 Int32
4-55 Warning Reference High 999999.999 All set-ups TRUE -3 Int32
4-56 Warning Feedback Low -999999.999 All set-ups TRUE -3 Int32
4-57 Warning Feedback High 999999.999 All set-ups TRUE -3 Int32
4-58 Missing Motor Phase Function [1] On All set-ups TRUE - Uint8
4-6* S peed Byp as s
4-60 Bypass Speed From [RPM] SR All set-ups TRUE 67 Uint16
4-61 Bypass Speed From [Hz] SR All set-ups TRU E -1 Uint16
4-62 Bypass Speed To [RPM] SR All set-ups TRUE 67 Uint16
4-63 Bypass Speed To [Hz] SR All set-ups TRUE -1 U int 16
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
47
MG.33.A7.02 - VLT is a registered Danfoss trademark
