Danfoss FC 300

FC 300 Operating Instructions
How to Programme
" 5-** Digital In/Out
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
5-0* Digital I/O mode
5-00 Digital I/O Mode [0] PNP All set-ups FALSE - Uint8
5-01 Terminal 27 Mode [0] Input All set-ups TRUE - Uint8
5-02 Terminal 29 Mode [0] Input All set-ups x TRUE - Uint8
5-1* Digital Inputs
5-10 Terminal 18 Digital Input - All set-ups TRUE - Uint8
5-11 Terminal 19 Digital Input - All set-ups TRUE - Uint8
5-12 Terminal 27 Digital Input - All set-ups TRUE - Uint8
5-13 Terminal 29 Digital Input - All set-ups x TRUE - Uint8
5-14 Terminal 32 Digital Input [0] No operation All set-ups TRUE - Uint8
5-15 Terminal 33 Digital Input [0] No operation All set-ups TRUE - Uint8
5-16 Terminal X30/2 Digital Input [0] No operation All set-ups TRUE - Uint8
5-17 Terminal X30/3 Digital Input [0] No operation All set-ups TRUE - Uint8
5-18 Terminal X30/4 Digital Input [0] No operation All set-ups TRUE - Uint8
5-3* Digital Outputs
5-30 Terminal 27 Digital Output - All set-ups TRUE - Uint8
5-31 Terminal 29 Digital Output - All set-ups x TRUE - Uint8
5-32 Te rm X30/6 Digi Out (MCB 101) - All set-ups TRUE - Uint8
5-33 Te rm X30/7 Digi Out (MCB 101) - All set-ups TRUE - Uint8
5-4* Relays
5-40 Functi on Relay - All set-ups TRUE - Uint8
5-41 On Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
5-42 Off Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
5-5* Pulse Input
5-50 Term. 29 Low Frequency 100 Hz All set-ups x TRUE 0 Uint32
5-51 Term. 29 High F requency 100 Hz All set-ups x TRUE 0 Uint32
5-52 Term. 29 Low Ref./Feedb. Value 0.000 All set-ups x TRUE -3 Int32
5-53 Term. 29 High Ref./Feedb. Value SR All set-ups x TRUE - 3 In t3 2
5-54 Pulse Filter Time Constant #29 100 ms All set-ups x FALSE -3 Uint16
5-55 Term. 33 Low Frequency 100 Hz All set-ups TRUE 0 Uint32
5-56 Term. 33 High F requency 100 Hz All set-ups TRUE 0 Uint32
5-57 Term. 33 Low Ref./Feedb. Value 0.000 All set-ups TRUE -3 Int32
5-58 Term. 33 High Ref./Feedb. Value SR All set-ups TRUE -3 Int32
5-59 Pulse Filter Time Constant #33 100 ms All set-ups FALSE -3 Uint16
5-6* P u l se Outp u t
5-60 Terminal 27 Pulse Output Variable - All set-ups TRU E - Uint8
5-62 Pulse Output Max Freq #27 SR All set-ups TRUE 0 Uint32
5-63 Terminal 29 Pulse Output Variable - All set-ups x TRUE - Uint8
5-65 Pulse Output Max Freq #29 SR All set-ups x TRUE 0 Uint32
5-66
Ter mi na l X3 0/ 6 P ulse O ut pu t
Variable - All set-ups TRUE - Uint8
5-68 Pulse Output Max Freq #X30/6 SR All set-ups TRUE 0 Uint32
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
48
MG.33.A7.02 - VLT is a registered Danfoss trademark
