FC 300 Instruction Manual
How to Install
UL Compliance
200-240 V
FC 30X Bussmann Bussmann Bussmann SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
kW Type RK1 Type J Type T Type RK1 Type RK1 Type C C Type RK1
2-7.5 KTN-R10 JKS-10 JJN-10 5017906-010 KLN-R10 ATM-R10 A2K-10R
1.1-2.2 KTN-R20 JKS-20 JJN-20 5017906-020 KLN-R20 ATM-R20 A2K-20R
3.0-3.7 KTN-R30 JKS-30 JJN-30 5012406-032 KLN-R30 ATM-R30 A2K-30R
380-500 V, 525-600 V
FC 30X Bussmann Bussmann Bussmann SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
kW Type RK1 Type J Type T Type RK1 Type RK1 Type CC Type RK1
0.37-1.5 KTS-R10 JKS-10 JJS-10 5017906-010 KLS-R10 ATM-R10 A6K-10R
2.2-4.0 KTS-R20 JKS-20 JJS-20 5017906-020 KLS-R20 ATM-R20 A6K-20R
5.5-7.5 KTS-R30 JKS-30 JJS-30 5012406-032 KLS-R30 ATM-R30 A6K-30R
11.0 KTS-R40 JKS-40 JJS-40 5014006-040 KLS-R40 A6K-40R
15.0 KTS-R50 JKS-50 JJS-50 5014006-050 KLS-R50 A6K-50R
18.0 KTS-R60 JKS-60 JJS-60 5014006-063 KLS-R60 A6K-60R
22.0 KTS-R80 JKS-80 JJS-80 5014006-100 KLS-R80 A6K-80R
KTS fuses from Bu
ssmann may substitute KTN for 240 V adjustable frequency drives.
FWH fuses from Bussmann may substitute FWX for 240 V adjustable frequency drives.
KLSR fuses from LITTEL FUS E may substitute KLNR fuses for 240 V ad justable frequency drives.
L50S fuses from LITT
EL FUSE may substitute L50S fuses for 240 V adjustable frequency drives.
A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V adjustable frequency drives.
A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V adjustable frequency drives.
22
MG.33.A6.22 - VLT is a registered Danfoss trademark
