Danfoss FC 300

FC 300 Instruction Manual
How to Program
" 0-** O p er at ion/Display
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
0-0* Basic settings
0-01 Language [0] English 1 set-up TRUE - U int8
0-04 Operating state at Power-up (Hand) [1] Forced stop, ref=old All set-ups TRUE - Uint8
0-1* Set-up handling
0-10 Active set-up [1] Setup 1 1 set-up TRUE - Uint8
0-11 Edit set-up [1] Setup 1 All set-ups TRUE - Uint8
0-12 This set-up linked to [1] Setup 1 All set-ups FALSE - Uint8
0-13 Readout: Linked set-ups 0 All set-ups FALSE 0 Uint16
0-14 Readout: Edit set-ups / channel 0 All set-ups TRUE 0 Uint32
0-2* LCP Display
0-20 Display line 1.1 small [1617] Speed (RPM) All se t-ups TRUE - Uint16
0-21 Display line 1.2 small [1614] Motor current All set-ups TRUE - Uint16
0-22 Display line 1.3 small [1610] Power (kW ) All set-ups TRUE - Uint16
0-23 Display line 2 large [1613] Frequency All set-ups TRUE - Uint16
0-24 Display line 3 large [1602] Reference % All set-ups TRUE - Uint16
0-25 My personal menu User depedent 1 set-up TRUE 0 Uint16
0-4* LCP keypad
0-40 [Hand on] key on LCP [1] Enabled All set-ups TRUE - Uint8
0-41 [Off] key on LCP [1] Enabled All set-ups TRUE - Uint8
0-42 [Auto on] key on LCP [1] Enabled All set-ups TRUE - U int8
0-43 [Reset] key on LCP [1] Enabled All set-ups TRUE - Uint8
0-5* Copy/Save
0-50 LCP copy [0] No copy All set-ups FALSE - Uint8
0-51 Set-up copy [0] No copy All set-ups FALSE - Uint8
0-6* Password
0-60 Main menu password 100 1 set-up TRUE 0 Uint16
0-61 Access to main menu w/o password [0] Full access 1 set-up TRUE - Uint8
0-64 Quick menu password 200 1 se t-up TRUE 0 Uint16
0-66 Access to quick menu w/o password [0] Full access 1 set-up TRUE - Uint8
*
default setting ()display text []value for use in comm unication via serial comm unication port
39
MG.33.A
