Danfoss FC 300 Instruction Manual

FC 300 Instruction Manual
How to Program
" 17-** Motor Feedb.Option
Par.
No.
#
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion in dex
Type
17-1* Inc. Enc. I nterface
17-10 Signal Type
[1] RS422 (5V
TTL/linedrv.) All set-ups FALSE - Uint8
17-11 Resolution (PPR) 1024 N/A All set-ups FALSE 0 Uint16
17-2*Abs.Enc.Interface
17-20 Protocol Selection [0] None All set-ups FALSE - Uint8
17-21 Resolution (Positions/Rev) [32768] 32768 All set-ups FALSE - Uint16
17-34 HIPERFACE Baudrate [4] 9600 All set-ups FALSE - Uint8
17-6* Monitoring and App.
17-60 Encoder Positive Direction [0] Clockwise All set-ups FALSE - Uint8
*
default setting ()display text []value for use in comm unication via serial comm unication port
52
MG.33.A
6.22 - VLT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
