How to Access FC 300 Parameters
Service Data Objects (SDO)
FC 300 parameters can be accessed by Service Data Objects, SDOs. The SDOs are used for
communicating non-time-critical data.
Structure of SDO COB-ID entry
Unsigned32
MSB LSB
bits
31 30 29 28-11 10-0
11-bit-ID 0/1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0
11-bit Identifier
29-bit-ID 0/1 0 1 29-bit Identifier
Description of SDO COB-ID entry
Bit number Value Meaning
0 SDO valid
31(MSB)
1 SDO not valid
30
0 Reserved (always 0)
0 11-bit ID (CAN 2.0A)
29
1 29-bit ID (CAN 2.0B)
0 If bit 29=0
28-11
X If bit 29=1: bits 28-11 of 29-bit-COB-ID
10-0 (LSB)
X Bits 10-0 of COB-ID
An SDO is only valid if both SDO-valid-bits are 0. Bit 29 may be static (not changeable) e.g. due to
hardware restrictions.
