FC 300 CANopen
50 MG.33.J1.02 VER. 050301 – VLT is a registered Danfoss trademark
Parameter List
PNU Parameter Default value Range Conversion Data
# Designation
index
type
8-01 Control Site Dig. and ctrl. word
[0]
[0 - 2] - 5
8-02 Control Word Source FC RS485 [1] [0 - 6] - 5
8-03 Control Word Timeout Time 1.0 s 0.1 - 18000 -1 7
8-04 Control Word Timeout
Function
Off [0]
[0 - 10] - 5
8-05 End-of-timeout Function Hold set-up [0] [0 - 1] - 5
8-06 Reset Control Word
Timeout
Do not reset [0] [0 - 1] - 5
8-07 Diagnosis Trigger Disable [0] [0 - 3] - 5
8-10 Control Word Profile FC profile [0] [0 - x] - 5
8-50 Coasting Select Logic OR [3] [0 - 3] - 5
8-51 Quick Stop Select Logic OR [3] [0 - 3] - 5
8-52 DC Brake Select Logic OR [3] [0 - 3] - 5
8-53 Start Select Logic OR [3] [0 - 3] - 5
8-54 Reversing Select Logic OR [3] [0 - 3] - 5
8-55 Set-up Select Logic OR [3] [0 - 3] - 5
8-56 Preset Reference Select Logic OR [3] [0 - 3] - 5
8-90 Bus Jog 1 Speed 100 rpm 0 - par.4-13 67 6
8-91 Bus Jog 2 Speed 200 rpm 0 - par.4-13 67 6
10-00 CAN Protocol
CANopen [0]
[0 ] - 5
10-01 Baud Rate Select
125 Kbps [20]
[16 – 22] - 5
10-02 Drive Node ID 127 0 - 127 0 5
10-05 Readout Transmit Error
Counter
0 0 - 255 0 5
10-06 Readout Receive Error
Counter
0 0 - 255 0 5
10-07 Readout Bus Off Counter 0 0 - 255 0 6
10-31 Store Data Values
Off [0]
[0 - 2] - 5
10-32 CANopen revision 0 0 - 65535 - 6
10-33 Store Always Off [0] [0 - 1] - 5
10-40 CANopen Process Data
Config. Write
None [0] [0 - 17]
10-41 CANopen Process Data
Config. Read
None [0] [0 - 48]
15-60 Option Mounted CANopen
16-48 Com Option STW [0 - 7]
16-90 Alarm Word 0 0 - FFFF 0 7
16-92 Warning Word 0 0 – FFFF 0 7
