FC 300 CANopen
MG.33.J1.02 VER. 050301 – VLT is a registered Danfoss trademark 49
Option:
*0 None
16-03 Status word
16-05 Main actual value (%)
16-00 Control Word
16-01 Reference (Unit)
16-02 Reference %
16-04 Main actual value (Unit)
16-91 Alarm word 2
16-92 Warning word
16-90 Alarm word
16-93 Warning word 2
16-94 Ext. status word
16-95 Ext. status word 2
16-10 Power (kW)
16-11 Power (hp)
16-12 Motor voltage
16-13 Frequency
16-14 Motor current
16-16 Torque
16-17 Speed (RPM)
16-18 Motor thermal
16-19 KTY sensor temperature
16-20 Phase angle
16-30 DC link Voltage
16-32 Brake energy/s
16-33 Brake energy/2 min
16-34 Heatsink temp.
16-35 Inverter thermal
16-38 SL controller state
16-39 Controlcard temp.
16-50 External reference
16-51 Pulse reference
16-52 Feedback (Unit)
16-53 Digi pot reference
16-60 Digital input
16-61 Terminal 53 switch setting
16-62 Analog input 53
16-63 Terminal 54 switch setting
16-64 Analog input 54
16-65 Analog output 42 (mA)
16-66 Digital output (bin)
16-67 Freq. input #29 (Hz)
16-68 Freq. input #33 (Hz)
16-69 Pulse output #27 (Hz)
16-70 Pulse output #29 (Hz)
16-84 Comm. option STW
16-85 FC port CTW 1
16-09 Custom readout
Function:
Only elements [2] and [3] of this array can be
selected ([0] and [1] are fixed).
15-60 Option mounted
Option:
Read only from LCP.
* CANopen
Function:
Shows the option type installed.
16-48 Com Option STW
Option:
Function:
Bit: Meaning:
0 COB RX overflow in interrupt handler,
messages lost
1 CAN overrun indicated by CAN
controller
2 CAN bus off
3 Controller status bit set
4 Controller status bit reset
5 Low priority tx queue full
7 Rx queue full
16-90 Alarm Word
Range:
0 - FFFF
* 0
Function:
Returns the alarm word sent via the serial
communication port in hex code.
16-92 Warning Word
Range:
0 - FFFF
* 0
Function:
Returns the warning word sent via the serial
communication port in hex code.
