Upload segment
The upload segment command is used when more than 5 bytes will be uploaded.
Client request:
0 Byte 1 8
7..5 ccs 4 t 3..0 X reserved
Server response:
0 Byte 1 8
7..5 ccs 4 x 3,2,1 n 0 c segment data
t: toggle bit
c: indicator for more segments
Byte 0
Bit 5-7 Bit 4 Bit 3..1 Bit 0
ccs / scs t toggle n c
0: Upload seg. Response
scs
0: 1. Seg
starts with 0
0: all data valid
(size 7 byte)
0: more segments to be
uploaded
1: - 1: byte 7 no data
(size 6 byte)
0: no more segments to be
uploaded
2: - …
3: Upload seg. Request
ccs
7: byte 2 - 7 no data
(size 1 byte)

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
