FC 300 Interbus
- How to Control the FC 300 -
MG.33.J1.02 VER. 050301 – VLT is a registered Danfoss trademark 27
Standardised Device Profile Area
State transitions
Transition State Control
word
Status
word
Action
Start condition 0000 0000
0 Startup -> Not Ready to Switch On 0000 0200
1 Not Ready to Switch On -> Switch On
Disabled
0000,
0001
0240
2 Switch On Disabled -> Ready to
Switch On
0006 0231
3 Ready to Switch On -> Switched On 0007 0233
4 Switched On -> Operation Enabled 000F 0237
5 Operation Enabled -> Switched On 0007 0233 Motor ramps to 0
RPM with
programmed ramp
down parameter
6 Switched On -> Ready to Switch On 0006 0231
7 Ready to Switch On -> Switch On
Disable
0001,
0000
0240
8 Operation Enable -> Ready to Switch
On
0006 0231 The power section is
switched off
immediately, and the
motor is free to
rotate if unbraked
9 Operation Enable -> Switch on Disable 0001,
0000
0240 The power section is
switched off
immediately, and the
motor is free to
rotate if unbraked
10 Switched On -> Switched On Disable 0001,
0000
0240 The power section is
switched off
immediately, and the
motor is free to
rotate if unbraked
11 Operation Enabled -> Quick Stop
Active
0002 0207 Motor ramps to 0
RPM with
programmed quick
ramp parameter
11 Operation Enabled -> Quick Stop
Active
0003 0217 Motor ramps to 0
RPM with
programmed quick
ramp parameter
12 Quick Stop Active -> Switch On
Disabled
0001,
0000
0240 The power section is
switched off
immediately, and the
motor is free to
rotate if unbraked
13 All states -> Fault Reaction Active xxxx 023F
14 Fault Reaction Active -> Fault xxxx 023F
(0238 by
Interbus)
15 Fault -> Switch On Disabled 0000 0240
16 Quick Stop Active -> Operation Enable
(not supported)
