Danfoss FC 301 Operating Guide

525–690 V
Recommended maximum fuse
Power [kW
(hp)]
Bussmann
Type RK1
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
1.1 (1.5) KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5
1.5–2.2
(2.0–3.0)
KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
3.0 (4.0) KTS-R15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
4.0 (5.0) KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
5.5 (7.5) KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
7.5 (10.0) KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
11.0 (15.0) KTS-R-35 JKS-35 JJS-35 – – –
15.0 (20.0) KTS-R-45 JKS-45 JJS-45 – – –
18.5 (25.0) KTS-R-50 JKS-50 JJS-50 – – –
22.0 (30.0) KTS-R-60 JKS-60 JJS-60 – – –
30.0 (40.0) KTS-R-80 JKS-80 JJS-80 – – –
37.0 (50.0) KTS-R-100 JKS-100 JJS-100 – – –
45.0 (60.0) KTS-R-125 JKS-125 JJS-125 – – –
55.0 (75.0) KTS-R-150 JKS-150 JJS-150 – – –
75.0
(100.0)
KTS-R-175 JKS-175 JJS-175 – – –
Table 8.22 525–690 V, Enclosure Sizes A, B, and C
Recommended maximum fuse
Power [kW
(hp)]
Maximum
pre-fuse
Bussmann
E52273
RK1/JDDZ
Bussmann
E4273
J/JDDZ
Bussmann
E4273
T/JDDZ
SIBA
E180276
RK1/JDDZ
Littelfuse
E81895
RK1/JDDZ
Ferraz
Shawmut
E163267/
E2137
RK1/JDDZ
Ferraz
Shawmut
E2137
J/HSJ
11.0 (15.0) 30 A KTS-R-30 JKS-30 JKJS-30 5017906-030 KLS-R-030 A6K-30-R HST-30
15–18.5
(20.0–25.0)
45 A KTS-R-45 JKS-45 JJS-45 5014006-050 KLS-R-045 A6K-45-R HST-45
22.0 (30.0) 60 A KTS-R-60 JKS-60 JJS-60 5014006-063 KLS-R-060 A6K-60-R HST-60
30.0 (40.0) 80 A KTS-R-80 JKS-80 JJS-80 5014006-080 KLS-R-075 A6K-80-R HST-80
37.0 (50.0) 90 A KTS-R-90 JKS-90 JJS-90 5014006-100 KLS-R-090 A6K-90-R HST-90
45.0 (60.0) 100 A KTS-R-100 JKS-100 JJS-100 5014006-100 KLS-R-100 A6K-100-R HST-100
55.0 (75.0) 125 A KTS-R-125 JKS-125 JJS-125 2028220-125 KLS-150 A6K-125-R HST-125
75.0 (100.0) 150 A KTS-R-150 JKS-150 JJS-150 2028220-150 KLS-175 A6K-150-R HST-150
Table 8.23 525–690 V, Enclosure Sizes B, and C
Specications
VLT
®
AutomationDrive FC 301/302
54 Danfoss A/S © 05/2018 All rights reserved. MG33AT02
88

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
