Danfoss FC 301 Operating Guide

8.1.2 Mains Supply 380–500 V
Type designation PK37 PK55 PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
Typical shaft output [kW/(hp)], high overload
0.37
(0.5)
0.55
(0.75)
0.75
(1.0)
1.1
(1.5)
1.5
(2.0)
2.2
(3.0)
3.0
(4.0)
4.0
(5.0)
5.5
(7.5)
7.5
(10)
Enclosure protection rating IP20 (FC 301 only) A1 A1 A1 A1 A1 – – – – –
Enclosure protection rating IP20, IP21 A2 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure protection rating IP55, IP66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current high overload 160% for 1 minute
Shaft output [kW/(hp)] 0.37
(0.5)
0.55
(0.75)
0.75
(1.0)
1.1
(1.5)
1.5
(2.0)
2.2
(3.0)
3.0
(4.0)
4.0
(5.0)
5.5
(7.5)
7.5
(10)
Continuous (380–440 V) [A] 1.3 1.8 2.4 3.0 4.1 5.6 7.2 10 13 16
Intermittent (380–440 V) [A] 2.1 2.9 3.8 4.8 6.6 9.0 11.5 16 20.8 25.6
Continuous (441–500 V) [A] 1.2 1.6 2.1 2.7 3.4 4.8 6.3 8.2 11 14.5
Intermittent (441–500 V) [A] 1.9 2.6 3.4 4.3 5.4 7.7 10.1 13.1 17.6 23.2
Continuous kVA (400 V) [kVA] 0.9 1.3 1.7 2.1 2.8 3.9 5.0 6.9 9.0 11
Continuous kVA (460 V) [kVA] 0.9 1.3 1.7 2.4 2.7 3.8 5.0 6.5 8.8 11.6
Maximum input current
Continuous (380–440 V) [A] 1.2 1.6 2.2 2.7 3.7 5.0 6.5 9.0 11.7 14.4
Intermittent (380–440 V) [A] 1.9 2.6 3.5 4.3 5.9 8.0 10.4 14.4 18.7 23
Continuous (441–500 V) [A] 1.0 1.4 1.9 2.7 3.1 4.3 5.7 7.4 9.9 13
Intermittent (441–500 V) [A] 1.6 2.2 3.0 4.3 5.0 6.9 9.1 11.8 15.8 20.8
Additional specications
IP20, IP21 maximum cable cross-section
2),5)
for
mains, motor, brake, and load sharing [mm
2
]
([AWG])
4, 4, 4 (12,12,12)
(minimum 0.2(24))
IP55, IP66 maximum cable cross-section
2),5)
for
mains, motor, brake, and load sharing [mm
2
]
([AWG])
4, 4, 4 (12,12,12)
Maximum cable cross-section
2),5)
for disconnect
[mm
2
] ([AWG])
6, 4, 4 (10,12,12)
Estimated power loss at rated maximum load
[W]
3)
35 42 46 58 62 88 116 124 187 255
Eciency
4)
0.93 0.95 0.96 0.96 0.97 0.97 0.97 0.97 0.97 0.97
Table 8.4 Mains Supply 380–500 V (FC 302), 380–480 V (FC 301), PK37–P7K5
Specications
VLT
®
AutomationDrive FC 301/302
34 Danfoss A/S © 05/2018 All rights reserved. MG33AT02
88

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
