Danfoss FC 301 Operating Guide

8 Specications
8.1 Electrical Data
8.1.1 Mains Supply 200–240 V
Type designation PK25 PK37 PK55 PK75 P1K1 P1K5 P2K2 P3K0 P3K7
Typical shaft output [kW/(hp)], high overload
0.25
(0.34)
0.37
(0.5)
0.55
(0.75)
0.75
(1.0)
1.1
(1.5)
1.5
(2.0)
2.2
(3.0)
3.0
(4.0)
3.7
(5.0)
Enclosure protection rating IP20 (FC 301 only) A1 A1 A1 A1 A1 A1 – – –
Enclosure protection rating IP20, IP21 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure protection rating IP55, IP66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current
Continuous (200–240 V) [A] 1.8 2.4 3.5 4.6 6.6 7.5 10.6 12.5 16.7
Intermittent (200–240 V) [A] 2.9 3.8 5.6 7.4 10.6 12.0 17.0 20.0 26.7
Continuous kVA (208 V) [kVA] 0.65 0.86 1.26 1.66 2.38 2.70 3.82 4.50 6.00
Maximum input current
Continuous (200–240 V) [A] 1.6 2.2 3.2 4.1 5.9 6.8 9.5 11.3 15.0
Intermittent (200–240 V) [A] 2.6 3.5 5.1 6.6 9.4 10.9 15.2 18.1 24.0
Additional specications
Maximum cable cross-section
2),5)
for mains,
motor, brake, and load sharing [mm
2
] ([AWG])
4, 4, 4 (12,12,12)
(minimum 0.2 (24))
Maximum cable cross-section
2),5)
for disconnect
[mm
2
] ([AWG])
6, 4, 4 (10,12,12)
Estimated power loss at rated maximum load
[W]
3)
21 29 42 54 63 82 116 155 185
Eciency
4)
0.94 0.94 0.95 0.95 0.96 0.96 0.96 0.96 0.96
Table 8.1 Mains Supply 200–240 V, PK25–P3K7
Type designation P5K5 P7K5 P11K
High/normal overload
1)
HO NO HO NO HO NO
Typical shaft output [kW/(hp)] 5.5 (7.5) 7.5 (10) 7.5 (10) 11 (15) 11 (15) 15 (20)
Enclosure protection rating IP20 B3 B3 B4
Enclosure protection rating IP21, IP55, IP66 B1 B1 B2
Output current
Continuous (200–240 V) [A] 24.2 30.8 30.8 46.2 46.2 59.4
Intermittent (60 s overload) (200–240 V) [A] 38.7 33.9 49.3 50.8 73.9 65.3
Continuous kVA (208 V) [kVA] 8.7 11.1 11.1 16.6 16.6 21.4
Maximum input current
Continuous (200–240 V) [A] 22.0 28.0 28.0 42.0 42.0 54.0
Intermittent (60 s overload) (200–240 V) [A] 35.2 30.8 44.8 46.2 67.2 59.4
Additional specications
IP20 maximum cable cross-section
2),5)
for mains, brake, motor, and
load sharing [mm
2
] ([AWG])
10, 10,- (8, 8,-) 10, 10,- (8, 8,-) 35,-,- (2,-,-)
IP21 maximum cable cross-section
2),5)
for mains, brake, and load
sharing [mm
2
] ([AWG])
16,10,16 (6, 8, 6) 16,10,16 (6, 8, 6) 35,-,- (2,-,-)
IP21 maximum cable cross-section
2),5)
for motor [mm
2
] ([AWG])
10, 10,- (8, 8,-) 10, 10,- (8, 8,-) 35,25,25 (2, 4, 4)
Maximum cable cross-section
2),5)
for disconnect [mm
2
] ([AWG])
16,10,10 (6, 8, 8)
Estimated power loss at rated maximum load [W]
3)
239 310 371 514 463 602
Eciency
4)
0.96 0.96 0.96
Table 8.2 Mains Supply 200–240 V, P5K5–P11K
Specications
VLT
®
AutomationDrive FC 301/302
32 Danfoss A/S © 05/2018 All rights reserved. MG33AT02
88

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
