Danfoss FC 301 Operating Guide

8.2 Mains Supply
Mains supply
Supply terminals (6-pulse) L1, L2, L3
Supply terminals (12-pulse) L1-1, L2-1, L3-1, L1-2, L2-2, L3-2
Supply voltage 200–240 V ±10%
Supply voltage FC 301: 380–480 V/FC 302: 380–500 V ±10%
Supply voltage FC 302: 525–600 V ±10%
Supply voltage FC 302: 525–690 V ±10%
Mains voltage low/mains dropout:
During low mains voltage or a mains dropout, the frequency converter continues until the DC-link voltage drops below the
minimum stop level, which corresponds typically to 15% below the frequency converter's lowest rated supply voltage. Power-up
and full torque cannot be expected at mains voltage lower than 10% below the frequency converter's lowest rated supply
voltage.
Supply frequency 50/60 Hz ±5%
Maximum imbalance temporary between mains phases 3.0% of rated supply voltage
True power factor (λ) ≥0.9 nominal at rated load
Displacement power factor (cos ϕ) Near unity (>0.98)
Switching on input supply L1, L2, L3 (power-ups) ≤7.5 kW (10 hp) Maximum twice per minute.
Switching on input supply L1, L2, L3 (power-ups) 11–75 kW (15–101 hp) Maximum once per minute.
Switching on input supply L1, L2, L3 (power-ups) ≥90 kW (121 hp) Maximum once per 2 minutes.
Environment according to EN60664-1 Overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100000 RMS symmetrical Amperes,
240/500/600/690 V maximum.
8.3
Motor Output and Motor Data
Motor output (U, V, W)
Output voltage 0–100% of supply voltage
Output frequency 0–590 Hz
1)
Output frequency in ux mode 0–300 Hz
Switching on output Unlimited
Ramp times 0.01–3600 s
1) Dependent on voltage and power.
Torque characteristics
Starting torque (constant torque) Maximum 160% for 60 s
1)
once in 10 minutes
Starting/overload torque (variable torque) Maximum 110% up to 0.5 s
1)
once in 10 minutes
Torque rise time in ux (for 5 kHz f
sw
) 1 ms
Torque rise time in VVC
+
(independent of f
sw
) 10 ms
1) Percentage relates to the nominal torque.
Specications Operating Guide
MG33AT02 Danfoss A/S © 05/2018 All rights reserved. 43
8 8

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
