9 Appendix
9.1 Symbols, Abbreviations, and Conventions
°C
Degrees Celsius
°F
Degrees Fahrenheit
AC Alternating current
AEO Automatic energy optimization
AWG American wire gauge
AMA Automatic motor adaptation
DC Direct current
EMC Electro-magnetic compatibility
ETR Electronic thermal relay
f
M,N
Nominal motor frequency
FC Frequency converter
I
INV
Rated inverter output current
I
LIM
Current limit
I
M,N
Nominal motor current
I
VLT,MAX
Maximum output current
I
VLT,N
Rated output current supplied by the frequency converter
IP Ingress protection
LCP Local control panel
MCT Motion control tool
n
s
Synchronous motor speed
P
M,N
Nominal motor power
PELV Protective extra low voltage
PCB Printed circuit board
PM Motor Permanent magnet motor
PWM Pulse width modulation
RPM Revolutions per minute
Regen Regenerative terminals
T
LIM
Torque limit
U
M,N
Nominal motor voltage
Table 9.1 Symbols and Abbreviations
Conventions
Numbered lists indicate procedures. Bullet lists indicate other information.
Italicized text indicates:
•
Cross-reference.
•
Link.
•
Parameter name.
•
Parameter group name.
•
Parameter option.
•
Footnote.
All dimensions in drawings are in [mm] (in).
