Danfoss FC 301 Operating Guide

8.7 Fuses and Circuit Breakers
Use recommended fuses and/or circuit breakers on the supply side as protection if there is component break-down inside
the frequency converter (rst fault).
NOTICE
Use of fuses on the supply side is mandatory for IEC 60364 (CE) and NEC 2009 (UL) compliant installations.
Recommendations
•
gG type fuses.
•
Moeller type circuit breakers. For other circuit breaker types, ensure that the energy into the frequency converter is
equal to or lower than the energy provided by Moeller types.
Use of recommended fuses and circuit breakers ensures that possible damage to the frequency converter is limited to
damage inside the unit. For further information, see Application Note Fuses and Circuit Breakers.
The fuses in chapter 8.7.1 CE Compliance to chapter 8.7.2 UL Compliance are suitable for use on a circuit capable of delivering
100000 A
rms
(symmetrical), depending on the frequency converter voltage rating. With the proper fusing, the frequency
converter short-circuit current rating (SCCR) is 100000 A
rms
.
8.7.1 CE Compliance
200–240 V
Enclosure Power [kW (hp)] Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker
Moeller
Maximum trip level
[A]
A1 0.25–1.5 (0.34–2.0) gG-10 gG-25 PKZM0-16 16
A2 0.25–1.5 (0.34–2.0) gG-10 gG-25 PKZM0-25 25
2.2 (3.0) gG-16
A3 3.0 (4.0) gG-16 gG-32 PKZM0-25 25
3.7 (5.0) gG-20
A4 0.25–1.5 (0.34–2.0) gG-10 gG-32 PKZM0-25 25
2.2 (3.0) gG-16
A5 0.25–1.5 (0.34–2.0) gG-10 gG-32 PKZM0-25 25
2.2–3.0 (3.0–4.0) gG-16
3.7 (5.0) gG-20
B1 5.5 (7.5) gG-25 gG-80 PKZM4-63 63
7.5 (10.0) gG-32
B2 11.0 (15.0) gG-50 gG-100 NZMB1-A100 100
B3 5.5 (7.5) gG-25 gG-63 PKZM4-50 50
B4 7.5 (10.0) gG-32 gG-125 NZMB1-A100 100
11.0 (15.0) gG-50
15.0 (20.0) gG-63
C1 15.0 (20.0) gG-63 gG-160 NZMB2-A200 160
18.5 (25.0) gG-80
22.0 (30.0) gG-100 aR-160
C2 30.0 (40.0) aR-160 aR-200 NZMB2-A250 250
37.0 (50.0) aR-200 aR-250
C3 18.5 (25.0) gG-80 gG-150 NZMB2-A200 150
22.0 (30.0) aR-125 aR-160
C4 30.0 (40.0) aR-160 aR-200 NZMB2-A250 250
37.0 (50.0) aR-200 aR-250
Table 8.13 200–240 V, Enclosure Sizes A, B, and C
Specications
VLT
®
AutomationDrive FC 301/302
48 Danfoss A/S © 05/2018 All rights reserved. MG33AT02
88

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
