Danfoss FC 301 Operating Guide

8.7.2 UL Compliance
200–240 V
Recommended maximum fuse
Power [kW
(hp)]
Bussmann
Type RK1
1)
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
0.25–0.37
(0.34–0.5)
KTN-R-05 JKS-05 JJN-05 FNQ-R-5 KTK-R-5 LP-CC-5
0.55–1.1
(0.75–1.5)
KTN-R-10 JKS-10 JJN-10 FNQ-R-10 KTK-R-10 LP-CC-10
1.5 (2.0) KTN-R-15 JKS-15 JJN-15 FNQ-R-15 KTK-R-15 LP-CC-15
2.2 (3.0) KTN-R-20 JKS-20 JJN-20 FNQ-R-20 KTK-R-20 LP-CC-20
3.0 (4.0) KTN-R-25 JKS-25 JJN-25 FNQ-R-25 KTK-R-25 LP-CC-25
3.7 (5.0) KTN-R-30 JKS-30 JJN-30 FNQ-R-30 KTK-R-30 LP-CC-30
5.5 (7.5) KTN-R-50 KS-50 JJN-50 – – –
7.5 (10.0) KTN-R-60 JKS-60 JJN-60 – – –
11.0 (15.0) KTN-R-80 JKS-80 JJN-80 – – –
15–18.5
(20.0–25.0)
KTN-R-125 JKS-125 JJN-125 – – –
22.0 (30.0) KTN-R-150 JKS-150 JJN-150 – – –
30.0 (40.0) KTN-R-200 JKS-200 JJN-200 – – –
37.0 (50.0) KTN-R-250 JKS-250 JJN-250 – – –
Table 8.17 200–240 V, Enclosure Sizes A, B, and C
Recommended maximum fuse
Power [kW
(hp)]
SIBA
Type RK1
Littelfuse
Type RK1
Ferraz-
Shawmut
Type CC
Ferraz-
Shawmut
Type RK1
3)
Bussmann
Type JFHR2
2)
Littelfuse
JFHR2
Ferraz-
Shawmut
JFHR2
4)
Ferraz-
Shawmut
J
0.25–0.37
(0.34–0.5)
5017906-005 KLN-R-05 ATM-R-05 A2K-05-R FWX-5 – – HSJ-6
0.55–1.1
(0.75–1.5)
5017906-010 KLN-R-10 ATM-R-10 A2K-10-R FWX-10 – – HSJ-10
1.5 (2.0) 5017906-016 KLN-R-15 ATM-R-15 A2K-15-R FWX-15 – – HSJ-15
2.2 (3.0) 5017906-020 KLN-R-20 ATM-R-20 A2K-20-R FWX-20 – – HSJ-20
3.0 (4.0) 5017906-025 KLN-R-25 ATM-R-25 A2K-25-R FWX-25 – – HSJ-25
3.7 (5.0) 5012406-032 KLN-R-30 ATM-R-30 A2K-30-R FWX-30 – – HSJ-30
5.5 (7.5) 5014006-050 KLN-R-50 – A2K-50-R FWX-50 – – HSJ-50
7.5 (10.0) 5014006-063 KLN-R-60 – A2K-60-R FWX-60 – – HSJ-60
11.0 (15.0) 5014006-080 KLN-R-80 – A2K-80-R FWX-80 – – HSJ-80
15–18.5
(20.0–25.0)
2028220-125 KLN-R-125 – A2K-125-R FWX-125 – – HSJ-125
22.0 (30.0) 2028220-150 KLN-R-150 – A2K-150-R FWX-150 L25S-150 A25X-150 HSJ-150
30.0 (40.0) 2028220-200 KLN-R-200 – A2K-200-R FWX-200 L25S-200 A25X-200 HSJ-200
37.0 (50.0) 2028220-250 KLN-R-250 – A2K-250-R FWX-250 L25S-250 A25X-250 HSJ-250
Table 8.18 200–240 V, Enclosure Sizes A, B, and C
1) KTS fuses from Bussmann may substitute KTN for 240 V frequency
converters.
2) FWH fuses from Bussmann may substitute FWX for 240 V
frequency converters.
3) A6KR fuses from Ferraz Shawmut may substitute A2KR for 240 V
frequency converters.
4) A50X fuses from Ferraz Shawmut may substitute A25X for 240 V
frequency converters.
Specications Operating Guide
MG33AT02 Danfoss A/S © 05/2018 All rights reserved. 51
8 8

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
