Danfoss FC 301 Operating Guide

380–500 V
Recommended maximum fuse
Power [kW (hp)]
Bussmann
Type RK1
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
0.37–1.1 (0.5–1.5) KTS-R-6 JKS-6 JJS-6 FNQ-R-6 KTK-R-6 LP-CC-6
1.5–2.2 (2.0–3.0) KTS-R-10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
3.0 (4.0) KTS-R-15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
4.0 (5.0) KTS-R-20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
5.5 (7.5) KTS-R-25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
7.5 (10.0) KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
11.0 (15.0) KTS-R-40 JKS-40 JJS-40 – – –
15.0 (20.0) KTS-R-50 JKS-50 JJS-50 – – –
18.5 (25.0) KTS-R-60 JKS-60 JJS-60 – – –
22.0 (30.0) KTS-R-80 JKS-80 JJS-80 – – –
30.0 (40.0) KTS-R-100 JKS-100 JJS-100 – – –
37.0 (50.0) KTS-R-125 JKS-125 JJS-125 – – –
45.0 (60.0) KTS-R-150 JKS-150 JJS-150 – – –
55.0 (75.0) KTS-R-200 JKS-200 JJS-200 – – –
75.0 (100.0) KTS-R-250 JKS-250 JJS-250 – – –
Table 8.19 380–500 V, Enclosure Sizes A, B, and C
Recommended maximum fuse
Power [kW (hp)]
SIBA
Type RK1
Littelfuse
Type RK1
Ferraz
Shawmut
Type CC
Ferraz
Shawmut
Type RK1
Bussmann
JFHR2
Ferraz
Shawmut
JFerraz
Shawmut
J
Ferraz
Shawmut
JFHR2
1)
Littelfuse
JFHR2
0.37–1.1 (0.5–1.5) 5017906-006 KLS-R-6 ATM-R-6 A6K-6-R FWH-6 HSJ-6 – –
1.5–2.2 (2.0–3.0) 5017906-010 KLS-R-10 ATM-R-10 A6K-10-R FWH-10 HSJ-10 – –
3.0 (4.0) 5017906-016 KLS-R-15 ATM-R-15 A6K-15-R FWH-15 HSJ-15 – –
4.0 (5.0) 5017906-020 KLS-R-20 ATM-R-20 A6K-20-R FWH-20 HSJ-20 – –
5.5 (7.5) 5017906-025 KLS-R-25 ATM-R-25 A6K-25-R FWH-25 HSJ-25 – –
7.5 (10.0) 5012406-032 KLS-R-30 ATM-R-30 A6K-30-R FWH-30 HSJ-30 – –
11.0 (15.0) 5014006-040 KLS-R-40 – A6K-40-R FWH-40 HSJ-40 – –
15.0 (20.0) 5014006-050 KLS-R-50 – A6K-50-R FWH-50 HSJ-50 – –
18.5 (25.0) 5014006-063 KLS-R-60 – A6K-60-R FWH-60 HSJ-60 – –
22.0 (30.0) 2028220-100 KLS-R-80 – A6K-80-R FWH-80 HSJ-80 – –
30.0 (40.0) 2028220-125 KLS-R-100 – A6K-100-R FWH-100 HSJ-100 – –
37.0 (50.0) 2028220-125 KLS-R-125 – A6K-125-R FWH-125 HSJ-125 – –
45.0 (60.0) 2028220-160 KLS-R-150 – A6K-150-R FWH-150 HSJ-150 – –
55.0 (75.0) 2028220-200 KLS-R-200 – A6K-200-R FWH-200 HSJ-200 A50-P-225 L50-S-225
75.0 (100.0) 2028220-250 KLS-R-250 – A6K-250-R FWH-250 HSJ-250 A50-P-250 L50-S-250
Table 8.20 380–500 V, Enclosure Sizes A, B, and C
1) Ferraz Shawmut A50QS fuses may substitute for A50P fuses.
Specications
VLT
®
AutomationDrive FC 301/302
52 Danfoss A/S © 05/2018 All rights reserved. MG33AT02
88

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
