Danfoss FC 301 Operating Guide

525–600 V
Enclosure Power [kW (hp)] Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker
Moeller
Maximum trip level
[A]
A2 0-75-4.0 (1.0–5.0) gG-10 gG-25 PKZM0-25 25
A3 5.5 (7.5) gG-10 gG-32 PKZM0-25 25
7.5 (10.0) gG-16
A5 5.5 (7.5) gG-10 gG-32 PKZM0-25 25
7.5 (10.0) gG-16
B1 11.0 (15.0) gG-25 gG-80 PKZM4-63 63
15.0 (20.0) gG-32
18.5 (25.0) gG-40
B2 22.0 (30.0) gG-50 gG-100 NZMB1-A100 100
30.0 (40.0) gG-63
B3 11.0 (15.0) gG-25 gG-63 PKZM4-50 50
15.0 (20.0) gG-32
B4 18.5 (25.0) gG-40 gG-125 NZMB1-A100 100
22.0 (30.0) gG-50
30.0 (40.0) gG-63
C1 37.0 (50.0) gG-63 gG-160 NZMB2-A200 160
45.0 (60.0) gG-100
55.0 (60.0) aR-160 aR-250
C2 75.0 (100.0) aR-200 aR-250 NZMB2-A250 250
C3 37.0 (50.0) gG-63 gG-150 NZMB2-A200 150
45.0 (60.0) gG-100 gG-150 NZMB2-A200
C4 55.0 (75.0) aR-160 aR-250 NZMB2-A250 250
75.0 (100.0) aR-200
Table 8.15 525–600 V, Enclosure Sizes A, B, and C
525–690 V
Enclosure Power [kW (hp)] Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker
Moeller
Maximum trip level
[A]
A3 1.1 (1.5)
1.5 (2.0)
2.2 (3.0)
3.0 (4.0)
4.0 (5.0)
5.5 (7.5)
7.5 (10.0)
gG-6
gG-6
gG-6
gG-10
gG-10
gG-16
gG-16
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
PKZM0-16 16
B2/B4 11.0 (15.0)
15.0 (20.0)
18.5 (25.0)
22.0 (30.0)
gG-25
gG-32
gG-32
gG-40
gG-63
– –
B4/C2 30.0 (40.0) gG-63 gG-80 – –
C2/C3 37.0 (50.0)
45.0 (60.0)
gG-63
gG-80
gG-100
gG-125
– –
C2 55.0 (75.0)
75.0 (100.0)
gG-100
gG-125
gG-160
– –
Table 8.16 525–690 V, Enclosure Sizes A, B, and C
Specications
VLT
®
AutomationDrive FC 301/302
50 Danfoss A/S © 05/2018 All rights reserved. MG33AT02
88

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
