Danfoss FC 301 Operating Guide

380–500 V
Enclosure Power [kW (hp)] Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker Moeller
Maximum trip level
[A]
A1 0.37–1.5 (0.5–2.0) gG-10 gG-25 PKZM0-16 16
A2 0.37–3.0 (0.5–4.0) gG-10 gG-25 PKZM0-25 25
4.0 (5.0) gG-16
A3 5.5–7.5 (7.5–10.0) gG-16 gG-32 PKZM0-25 25
A4 0.37–3.0 (0.5–4.0) gG-10 gG-32 PKZM0-25 25
4.0 (5.0) gG-16
A5 0.37–3.0 (0.5–4.0) gG-10 gG-32 PKZM0-25 25
4.0–7.5 (5.0–10.0) gG-16
B1 11–15 (15.0–20.0) gG-40 gG-80 PKZM4-63 63
B2 18.5 (25.0) gG-50 gG-100 NZMB1-A100 100
22.0 (30.0) gG-63
B3 11–15 (15.0–20.0) gG-40 gG-63 PKZM4-50 50
B4 18.5 (25.0) gG-50 gG-125 NZMB1-A100 100
22.0 (30.0) gG-63
30.0 (40.0) gG-80
C1 30.0 (40.0) gG-80 gG-160 NZMB2-A200 160
37.0 (50.0) gG-100
45.0 (60.0) gG-160
C2 55.0 (75.0) aR-200 aR-250 NZMB2-A250 250
75.0 (100.0) aR-250
C3 37.0 (50.0) gG-100 gG-150 NZMB2-A200 150
45.0 (60.0) gG-160 gG-160
C4 55.0 (75.0) aR-200 aR-250 NZMB2-A250 250
75.0 (100.0) aR-250
Table 8.14 380–500 V, Enclosure Sizes A, B, and C
Specications Operating Guide
MG33AT02 Danfoss A/S © 05/2018 All rights reserved. 49
8 8

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
