Danfoss FC 301 Operating Guide

Type designation P11K P15K P18K P22K
High/normal overload
1)
HO NO HO NO HO NO HO NO
Typical shaft output [kW/(hp)] 11 (15) 15 (20) 15 (20) 18.5 (25) 18.5 (25) 22 (30) 22 (30) 30 (40)
Enclosure protection rating IP20 B3 B3 B4 B4
Enclosure protection rating IP21, IP55, IP66 B1 B1 B2 B2
Output current
Continuous (380–440 V) [A] 24 32 32 37.5 37.5 44 44 61
Intermittent (60 s overload) (380–440 V) [A] 38.4 35.2 51.2 41.3 60 48.4 70.4 67.1
Continuous (441–500 V) [A] 21 27 27 34 34 40 40 52
Intermittent (60 s overload)
(441–500 V) [A]
33.6 29.7 43.2 37.4 54.4 44 64 57.2
Continuous kVA (400 V) [kVA] 16.6 22.2 22.2 26 26 30.5 30.5 42.3
Continuous kVA (460 V) [kVA] – 21.5 – 27.1 – 31.9 – 41.4
Maximum input current
Continuous (380–440 V) [A] 22 29 29 34 34 40 40 55
Intermittent (60 s overload)
(380–440 V) [A]
35.2 31.9 46.4 37.4 54.4 44 64 60.5
Continuous (441–500 V) [A] 19 25 25 31 31 36 36 47
Intermittent (60 s overload)
(441–500 V) [A]
30.4 27.5 40 34.1 49.6 39.6 57.6 51.7
Additional specications
IP21, IP55, IP66 maximum cable cross-
section
2),5)
for mains, brake, and load sharing
[mm
2
] ([AWG])
16, 10, 16 (6, 8, 6) 16, 10, 16 (6, 8, 6) 35,-,-(2,-,-) 35,-,-(2,-,-)
IP21, IP55, IP66 maximum cable cross-
section
2),5)
for motor [mm
2
] ([AWG])
10, 10,- (8, 8,-) 10, 10,- (8, 8,-) 35, 25, 25 (2, 4, 4) 35, 25, 25 (2, 4, 4)
IP20 maximum cable cross-section
2),5)
for
mains, brake, motor, and load sharing [mm
2
]
([AWG])
10, 10,- (8, 8,-) 10, 10,- (8, 8,-) 35,-,-(2,-,-) 35,-,-(2,-,-)
Maximum cable cross-section
2),5)
for
disconnect [mm
2
] ([AWG])
16, 10, 10 (6, 8, 8)
Estimated power loss at rated maximum load
[W]
3)
291 392 379 465 444 525 547 739
Eciency
4)
0.98 0.98 0.98 0.98
Table 8.5 Mains Supply 380–500 V (FC 302), 380–480 V (FC 301), P11K–P22K
Specications Operating Guide
MG33AT02 Danfoss A/S © 05/2018 All rights reserved. 35
8 8

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
