Danfoss FC 301 Operating Guide

Type designation P30K P37K P45K P55K P75K
High/normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output [kW/(hp)] 30 (40) 37 (50) 37 (50) 45 (60) 45 (60) 55 (75) 55 (75) 75 (100) 75 (100) 90 (125)
Enclosure protection rating IP20 B4 C3 C3 C4 C4
Enclosure protection rating IP21,
IP55, IP66
C1 C1 C1 C2 C2
Output current
Continuous (380–440 V) [A] 61 73 73 90 90 106 106 147 147 177
Intermittent (60 s overload)
(380–440 V) [A]
91.5 80.3 110 99 135 117 159 162 221 195
Continuous (441–500 V) [A] 52 65 65 80 80 105 105 130 130 160
Intermittent (60 s overload)
(441–500 V) [A]
78 71.5 97.5 88 120 116 158 143 195 176
Continuous kVA (400 V) [kVA] 42.3 50.6 50.6 62.4 62.4 73.4 73.4 102 102 123
Continuous kVA (460 V) [kVA] – 51.8 – 63.7 – 83.7 – 104 – 128
Maximum input current
Continuous (380–440 V) [A] 55 66 66 82 82 96 96 133 133 161
Intermittent (60 s overload) (380–
440 V) [A]
82.5 72.6 99 90.2 123 106 144 146 200 177
Continuous (441–500 V) [A] 47 59 59 73 73 95 95 118 118 145
Intermittent (60 s overload) (441–
500 V) [A]
70.5 64.9 88.5 80.3 110 105 143 130 177 160
Additional specications
IP20 maximum cable cross-
section
5)
for mains and motor
[mm
2
] ([AWG])
35 (2) 50 (1) 50 (1) 150 (300 MCM) 150 (300 MCM)
IP20 maximum cable cross-
section
5)
for brake and load
sharing [mm
2)
] ([AWG])
35 (2) 50 (1) 50 (1) 95 (4/0) 95 (4/0)
IP21, IP55, IP66 maximum cable
cross-section
5)
for mains and motor
[mm
2
] ([AWG])
50 (1) 50 (1) 50 (1) 150 (300 MCM) 150 (300 MCM)
IP21, IP55, IP66 maximum cable
cross-section
5)
for brake and load
sharing [mm
2
] ([AWG])
50 (1) 50 (1) 50 (1) 95 (3/0) 95 (3/0)
Maximum cable cross-section
2),5)
for mains disconnect [mm
2
]
([AWG])
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350 MCM, 300
MCM, 4/0)
Estimated power loss
at rated maximum load [W]
3)
570 698 697 843 891 1083 1022 1384 1232 1474
Eciency
4)
0.98 0.98 0.98 0.98 0.99
Table 8.6 Mains Supply 380–500 V (FC 302), 380–480 V (FC 301), P30K–P75K
Specications
VLT
®
AutomationDrive FC 301/302
36 Danfoss A/S © 05/2018 All rights reserved. MG33AT02
88

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
