Danfoss Metasys N2 Operating Instructions

4.
Press [
◀
] to highlight the 3rd digit before the
comma.
5.
Change '0' to '1' by pressing [
▲
].
6.
Press [
▶
] to highlight the digit '2'.
7.
Change '2' to '0' by pressing [
▼
].
8. Press [OK].
The new ramp-down time is now set to 100 s.
It is recommended to do the set-up in the order listed.
NOTICE
130BP064.10
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
40.0% 4.84 A 1(1)
Quick Menus
Illustration 6.1 Quick Menu View
The Quick Setup menu gives access to the 18 most
important setup parameters of the frequency converter.
After programming, the frequency converter is ready for
operation. The 18 Quick Set-up parameters are shown in
Table 6.2.
Parameter [Units]
Parameter 0-01 Language
Parameter 1-20 Motor Power [kW] [kW]
Parameter 1-21 Motor Power [HP] [HP]
Parameter 1-22 Motor Voltage* [V]
Parameter 1-23 Motor Frequency [Hz]
Parameter 1-24 Motor Current [A]
Parameter 1-25 Motor Nominal Speed [RPM]
Parameter 1-28 Motor Rotation Check [Hz]
Parameter 3-41 Ramp 1 Ramp Up Time [s]
Parameter 3-42 Ramp 1 Ramp Down
Time
[s]
Parameter 4-11 Motor Speed Low
Limit [RPM]
[RPM]
Parameter 4-12 Motor Speed Low
Limit [Hz]*
[Hz]
Parameter 4-13 Motor Speed High
Limit [RPM]
[RPM]
Parameter 4-14 Motor Speed High
Limit [Hz]*
[Hz]
3-19 Jog Speed [RPM] [RPM]
Parameter 3-11 Jog Speed [Hz]* [Hz]
5-12 Terminal 27 Digital Input
Parameter 5-40 Function Relay**
Table 6.2 Quick Setup Parameters
*The display showing depends on choices made in 0-02 Motor Speed
Unit and 0-03 Regional Settings. The default settings of 0-02 Motor
Speed Unit and 0-03 Regional Settings depend on which region of
the world the frequency converter is supplied to but can be re-
programmed as required.
** Parameter 5-40 Function Relay is an array. Select between [0]
Relay1 or [1] Relay2 . Standard setting is [0] Relay1 with the default
choice [9] Alarm.
For a detailed information about settings and
programming, see the VLT HVAC Drive Programming Guide
NOTICE
If [0] No Operation is selected in 5-12 Terminal 27 Digital
Input, no connection to +24 V on terminal 27 is
necessary to enable start.
If [2] Coast Inverse (factory default value) is selected in
5-12 Terminal 27 Digital Input, a connection to +24 V is
necessary to enable start.
0-01 Language
Option: Function:
Defines the language to be used in the
display. The frequency converter is
delivered with 4 different language
packages English and German are included
in all packages. English cannot be erased
or manipulated.
[0] * English Part of Language packages 1 - 4
[1] Deutsch Part of Language packages 1 - 4
[2] Francais Part of Language package 1
[3] Dansk Part of Language package 1
[4] Spanish Part of Language package 1
[5] Italiano Part of Language package 1
[6] Svenska Part of Language package 1
[7] Nederlands Part of Language package 1
[10] Chinese Part of Language package 2
[20] Suomi Part of Language package 1
[22] English US Part of Language package 4
[27] Greek Part of Language package 4
[28] Bras.port Part of Language package 4
[36] Slovenian Part of Language package 3
[39] Korean Part of Language package 2
[40] Japanese Part of Language package 2
[41] Turkish Part of Language package 4
[42] Trad.Chinese Part of Language package 2
[43] Bulgarian Part of Language package 3
[44] Srpski Part of Language package 3
How to Programme VLT HVAC Drive FC 102 Operating Instructions
MG11F402 - Rev. 2013-12-16 85
6 6
