3-11 Jog Speed [Hz]
Range: Function:
Size
related*
[ 0 - par.
4-14 Hz]
The jog speed is a fixed output speed
at which the frequency converter is
running when the jog function is
activated.
See also 3-80 Jog Ramp Time.
3-41 Ramp 1 Ramp Up Time
Range: Function:
Size
related*
[ 1.00 -
3600 s]
Enter the ramp-up time, i.e. the
acceleration time from 0 RPM to
parameter 1-25 Motor Nominal Speed.
Select a ramp-up time such that the
output current does not exceed the
current limit in 4-18 Current Limit during
ramping. See ramp-down time in
parameter 3-42 Ramp 1 Ramp Down Time.
par .3− 41 =
tacc × nnom par .1− 25
ref rpm
s
3-42 Ramp 1 Ramp Down Time
Range: Function:
Size
related*
[ 1.00 -
3600 s]
Enter the ramp-down time, i.e. the
deceleration time from
parameter 1-25 Motor Nominal Speed to 0
RPM. Select a ramp-down time such that no
over-voltage arises in the inverter due to
regenerative operation of the motor, and
such that the generated current does not
exceed the current limit set in 4-18 Current
Limit. See ramp-up time in
parameter 3-41 Ramp 1 Ramp Up Time.
par .3− 42 =
tdec × nnom par .1− 25
ref rpm
s
4-11 Motor Speed Low Limit [RPM]
Range: Function:
Size
related*
[ 0 - par.
4-13
RPM]
Enter the minimum limit for motor speed.
The motor speed low limit can be set to
correspond to the manufacturer’s
recommended minimum motor speed.
The motor speed low limit must not
exceed the setting in
parameter 4-13 Motor Speed High Limit
[RPM].
4-12 Motor Speed Low Limit [Hz]
Range: Function:
Size
related*
[ 0 -
par. 4-14
Hz]
Enter the minimum limit for motor speed.
The motor speed low limit can be set to
correspond to the minimum output
frequency of the motor shaft. The speed
low limit must not exceed the setting in
parameter 4-14 Motor Speed High Limit
[Hz].
4-13 Motor Speed High Limit [RPM]
Range: Function:
Size
related*
[ par.
4-11 -
60000
RPM]
Enter the maximum limit for motor speed.
The motor speed high limit can be set to
correspond to the manufacturer’s
maximum rated motor. The motor speed
high limit must exceed the setting in
parameter 4-11 Motor Speed Low Limit
[RPM]. Only parameter 4-11 Motor Speed
Low Limit [RPM] or parameter 4-12 Motor
Speed Low Limit [Hz] is displayed
depending on other parameters in the
Main Menu and depending on default
settings dependant on global location.
NOTICE
Max. output frequency cannot exceed 10% of the
inverter switching frequency (parameter 14-01 Switching
Frequency).
NOTICE
Any changes in parameter 4-13 Motor Speed High Limit
[RPM] reset the value in parameter 4-53 Warning Speed
High to the same value as set in parameter 4-13 Motor
Speed High Limit [RPM].
4-14 Motor Speed High Limit [Hz]
Range: Function:
Size
related*
[ par.
4-12 -
par. 4-19
Hz]
Enter the max limit for motor speed.
parameter 4-14 Motor Speed High Limit [Hz]
can match the manufacturer's
recommended maximum motor speed.
The Motor Speed High Limit must exceed
the value in parameter 4-12 Motor Speed
Low Limit [Hz]. The output frequency must
not exceed 10% of the switching
frequency.
NOTICE
Max. output frequency cannot exceed 10% of the
inverter switching frequency (parameter 14-01 Switching
Frequency).
How to Programme VLT HVAC Drive FC 102 Operating Instructions
MG11F402 - Rev. 2013-12-16 87
6 6
