Danfoss Metasys N2 Operating Instructions

0-01 Language
Option: Function:
[45] Romanian Part of Language package 3
[46] Magyar Part of Language package 3
[47] Czech Part of Language package 3
[48] Polski Part of Language package 4
[49] Russian Part of Language package 3
[50] Thai Part of Language package 2
[51] Bahasa
Indonesia
Part of Language package 2
[52] Hrvatski Part of Language package 3
1-20 Motor Power [kW]
Range: Function:
Size
related*
[ 0.09 -
3000.00
kW]
Enter the nominal motor power in kW
according to the motor nameplate data.
The default value corresponds to the
nominal rated output of the unit.
Depending on the choices made in
0-03 Regional Settings, either
parameter 1-20 Motor Power [kW] or
parameter 1-21 Motor Power [HP] is made
invisible.
1-21 Motor Power [HP]
Range: Function:
Size
related*
[ 0.09 -
3000.00
hp]
Enter the nominal motor power in HP
according to the motor nameplate data.
The default value corresponds to the
nominal rated output of the unit.
Depending on the choices made in
0-03 Regional Settings, either
parameter 1-20 Motor Power [kW] or
parameter 1-21 Motor Power [HP] is made
invisible.
1-22 Motor Voltage
Range: Function:
Size
related*
[ 10 -
1000 V]
Enter the nominal motor voltage
according to the motor nameplate
data. The default value corresponds to
the nominal rated output of the unit.
1-23 Motor Frequency
Range: Function:
Size
related*
[20 -
1000
Hz]
Select the motor frequency value from the
motor nameplate data. For 87 Hz operation
with 230/400 V motors, set the nameplate
data for 230 V/50 Hz. Adapt
parameter 4-13 Motor Speed High Limit [RPM]
1-23 Motor Frequency
Range: Function:
and 3-03 Maximum Reference to the 87 Hz
application.
1-24 Motor Current
Range: Function:
Size
related*
[ 0.10 -
10000.00 A]
Enter the nominal motor current
value from the motor nameplate
data. This data is used for
calculating motor torque, motor
thermal protection etc.
1-25 Motor Nominal Speed
Range: Function:
Size related* [100 - 60000
RPM]
Enter the nominal motor speed
value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
1-28 Motor Rotation Check
Option: Function:
Following installation and connection of the
motor, this function allows the correct motor
rotation direction to be verified. Enabling this
function overrides any bus commands or digital
inputs, except External Interlock and Safe Stop (if
included).
[0] * Off
Motor Rotation Check is not active.
[1] Enabled Motor Rotation Check is enabled.
NOTICE
Once the motor rotation check is enabled the display
shows: Note! Motor may run in wrong direction.
Pressing [OK], [Back] or [Cancel] dismisses the message
and displays a new message: “Press [Hand On] to start
the motor. Press [Cancel] to abort”. Pressing [Hand On]
starts the motor at 5 Hz in forward direction and the
display shows: “Motor is running. Check if motor rotation
direction is correct. Press [Off] to stop the motor”.
Pressing [Off] stops the motor and resets
parameter 1-28 Motor Rotation Check. If motor rotation
direction is incorrect, 2 motor phase cables should be
interchanged.
WARNING
Remove mains power before disconnecting motor phase
cables.
How to Programme VLT HVAC Drive FC 102 Operating Instructions
86 MG11F402 - Rev. 2013-12-16
66
