Danfoss Series 42 Service Manual

Case drain plug
F091 28/32 cm
3
41/51 cm
3
Internal hex 9/16 in 5/8 in
Torque 120 N•m
[89 lbf•ft]
200 N•m
[150 lbf•ft]
Size and torque for plugs and fittings
Servo gauge
port M4
Case drain
port L1
Charge pressure
gauge port M3
(position varies,
refer to Filtration
options)
Charge pump
inlet port S
F091
(see table)
L010
/ in
37 N•m
[27 lbf•ft]
11
16
Servo gauge
port M5
N002
/ in
37 N•m
[27 lbf•ft]
11
16
M010
/ in
37 N•m
[27 lbf•ft]
11
16
F093
/ in
37 N•m
[27 lbf•ft]
11
16
System po
rts
A and B
F091
(see table)
Case drain
port L2
System
gauge po
rts
M1 and M2
P108 097E
Service Manual Series 42 Axial Piston Closed Circuit Pumps
Minor Repair
36 520L0638 • Rev 0300 • July 2015
