Torque table
Sequence
Number
Part Description Tool Type Tool Size Torque
N•m [lbf•ft]
D002 MDC bolts Torx wrench/ Internal hex T-30/5 mm 17 [13]
D003 Cover plug Internal hex wrench 3/16 in 13 [9.5]
D010 Linkage pivot screw Internal hex wrench 4 mm 11 [8]
D015 MDC/EDC/HC-EDC neutral
adjustment seal lock nut
External hex wrench 17 mm 40 [30]
D032 Control spool bore plug External hex wrench 7/8 in 70 [52]
D035 Control spool bore plug Internal hex wrench 5/16 in 70 [52]
D038 Control nut External hex wrench 8 mm 6 [4.4]
D040 Neutral start switch External hex wrench 7/8 in 27 [20]
D056A Retaining nut External hex wrench 3/4 in 6 [4.4]
D081 FNR/NFPE bolts Internal hex wrench 4 mm 7 [5]
D081/D082 EDC/HC-EDC bolts Torx wrench/ Internal hex T-30/5 mm 17 [13]
E051 NFPH orifice Internal hex wrench 3 mm 3 [2.2]
F091 Case drain plug (28/32 cm
3
) Internal hex wrench 9/16 in 120 [89]
F091 Case drain plug (41/51 cm
3
) Internal hex wrench 5/8 in 200 [150]
F093 System gauge ports M1 and M2
plugs
External hex wrench 11/16 in 37 [27]
G040 Shim adjustable charge relief valve
plug
External hex wrench 1 in 90 [66]
K007 Valve seat plug
(with bypass)
External hex wrench 1 in 70 [52]
K007 Valve seat plug
(without bypass)
Internal hex wrench 5/16 in 70 [52]
L005/M005 Servo piston cover bolts Torx wrench/ Internal hex T-30/5 mm 17 [13]
L010/M010 Servo gauge plug External hex wrench 11/16 in 37 [27]
L025/M025 Displacement limiter seal lock nut External hex wrench 13 mm 23 [17]
N002 Port N plug External hex wrench 11/16 in 37 [27]
P036 Control spool cover screws
(pre-block point change)
Torx wrench/ Internal hex T-30/5 mm 16 [12]
Q050B Loop flushing plug
(pre-block point change)
Internal hex wrench 1/4 in 6 [4.4]
Q050B Loop flushing plug
(post-block point change)
External hex wrench 11/16 in 37 [27]
Q060B Loop flushing relief valve plug External hex wrench 5/8 in 27 [20]
R042 Filtration adapter bolts Torx wrench/ Internal hex T-30/5 mm 17 [13]
T041 Lock nut (28/32 cm
3
) External hex wrench 1 1/16 in 24 [18]
T041 Lock nut (41/51 cm
3
) External hex wrench 1 1/16 in 40 [30]
T060 Pump mechanical neutral
adjustment seal lock nut (28/32
cm
3
, MDC/EDC/HC-EDC)
External hex wrench 13 mm 23 [17]
T060 Pump mechanical neutral
adjustment seal lock nut (28/32
cm
3
, NFP control and 41/51 cm
3
, all
controls)
External hex wrench 17 mm 40 [30]
Service Manual Series 42 Axial Piston Closed Circuit Pumps
Appendix A - Torques
68 520L0638 • Rev 0300 • July 2015
