If so required, fix spacer with Vaseline.
Use marks to ensure alignment.
13. Mount the 3 short bolts (38) in the right holes and mount 6 long bolts (37).
14. Tighten all bolts with a torque of 110±10 Nm [973.58 ±88.51 lbf·in].
Repair Instruction
Orbital Motors TMT, TMT FL and TMT W FL
Assembly of TMT
520L0351 • Rev EA • Feb 2014 47
