Danfoss VACON 1000 User Manual

AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-438-030+G2CE
438
2270
321
1660
4710
1400
2796
6950
VACON1000-
ED-560-030+G2CE
560
2900
410
2130
5010
1400
2796
8300
VACON1000-
ED-680-030+G2CE
680
3530
498
2580
5010
1400
2796
9350
Table 16: Nominal Voltage 3300 V, 18-pulse, 3 Power Cells per Phase, 50 Hz
AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-036-033+G2CE
36
200
26
140
1210
1250
2796
2200
VACON1000-
ED-050-033+G2CE
50
280
36
200
1210
1250
2796
2250
VACON1000-
ED-070-033+G2CE
70
400
51
290
1210
1250
2796
2300
VACON1000-
ED-090-033+G2CE
90
510
66
370
1610
1250
2888
3050
VACON1000-
ED-100-033+G2CE
100
570
73
410
1610
1250
2888
3100
VACON1000-
ED-120-033+G2CE
120
680
88
500
1610
1250
2888
3150
VACON1000-
ED-140-033+G2CE
140
800
102
580
1610
1250
2888
3200
VACON1000-
ED-150-033+G2CE
150
850
110
620
1910
1250
2888
4550
VACON1000-
ED-180-033+G2CE
180
1020
132
750
1910
1250
2888
4600
VACON1000-
ED-190-033+G2CE
190
1080
139
790
1910
1250
2888
4650
VACON1000-
ED-215-033+G2CE
215
1220
157
890
1910
1250
2888
4700
VACON1000-
ED-250-033+G2CE
250
1420
183
1040
4110
1400
2796
5300
VACON1000-
ED-305-033+G2CE
305
1740
223
1270
4110
1400
2796
5800
VACON1000-
ED-350-033+G2CE
350
2000
256
1460
4110
1400
2796
6100
AQ363633621020en-000201 / 172F3117 | 113Danfoss A/S © 2021.06
