Danfoss VACON 1000 User Manual

AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-438-033+G2CE
438
2500
321
1830
4710
1400
2796
7450
VACON1000-
ED-560-033+G2CE
560
3200
410
2340
5010
1400
2796
8700
VACON1000-
ED-680-033+G2CE
680
3880
498
2840
5010
1400
2796
9950
Table 17: Nominal Voltage 4160 V, 24-pulse, 4 Power Cells per Phase, 50 Hz
AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-036-041+G2CE
36
250
26
180
1210
1250
2796
2400
VACON1000-
ED-050-041+G2CE
50
360
36
250
1210
1250
2796
2450
VACON1000-
ED-070-041+G2CE
70
500
51
360
1210
1250
2796
2500
VACON1000-
ED-090-041+G2CE
90
640
66
470
1610
1250
2888
3250
VACON1000-
ED-100-041+G2CE
100
720
73
520
1610
1250
2888
3300
VACON1000-
ED-120-041+G2CE
120
860
88
630
1610
1250
2888
3350
VACON1000-
ED-140-041+G2CE
140
1000
102
730
1610
1250
2888
3400
VACON1000-
ED-150-041+G2CE
150
1080
110
790
1910
1250
2888
4750
VACON1000-
ED-180-041+G2CE
180
1290
132
950
1910
1250
2888
4800
VACON1000-
ED-190-041+G2CE
190
1360
139
1000
1910
1250
2888
4850
VACON1000-
ED-215-041+G2CE
215
1540
157
1130
1910
1250
2888
4900
VACON1000-
ED-250-041+G2CE
250
1800
183
1310
4610
1400
2796
6150
VACON1000-
ED-305-041+G2CE
305
2190
223
1600
4610
1400
2796
6850
VACON1000-
ED-350-041+G2CE
350
2520
256
1840
4610
1400
2796
7450
AQ363633621020en-000201 / 172F3117114 | Danfoss A/S © 2021.06
Specifications
VACON® 1000
Operating Guide
