Danfoss VACON 1000 User Manual

AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-438-041+G2CE
438
3150
321
2310
5410
1400
2796
9000
VACON1000-
ED-560-041+G2CE
560
4030
410
2950
5410
1400
2796
10700
VACON1000-
ED-680-041+G2CE
680
4890
498
3580
5810
1400
2796
11950
Table 18: Nominal Voltage 6000 V, 30-pulse, 5 Power Cells per Phase, 50 Hz
AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-036-060+G2CE
36
370
26
270
2310
1250
2796
3500
VACON1000-
ED-050-060+G2CE
50
510
36
370
2310
1250
2796
3550
VACON1000-
ED-070-060+G2CE
70
720
51
530
2310
1250
2796
3600
VACON1000-
ED-090-060+G2CE
90
930
66
680
2710
1250
2888
4850
VACON1000-
ED-100-060+G2CE
100
1030
73
750
2710
1250
2888
4900
VACON1000-
ED-120-060+G2CE
120
1240
88
910
2710
1250
2888
4950
VACON1000-
ED-140-060+G2CE
140
1450
102
1060
2710
1250
2888
5000
VACON1000-
ED-150-060+G2CE
150
1550
110
1140
3010
1250
2888
5850
VACON1000-
ED-180-060+G2CE
180
1870
132
1370
3010
1250
2888
5900
VACON1000-
ED-190-060+G2CE
190
1970
139
1440
3010
1250
2888
5950
VACON1000-
ED-215-060+G2CE
215
2230
157
1630
3010
1250
2888
6000
VACON1000-
ED-250-060+G2CE
250
2590
183
1900
5160
1400
2796
7700
VACON1000-
ED-305-060+G2CE
305
3160
223
2310
5160
1400
2796
8600
VACON1000-
ED-350-060+G2CE
350
3630
256
2660
5160
1400
2796
9200
AQ363633621020en-000201 / 172F3117 | 115Danfoss A/S © 2021.06
