Danfoss VACON 1000 User Manual

AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-061-030+GAUL
61
310
44
220
1210
1250
2796
2175
VACON1000-
ED-070-030+GAUL
70
360
51
260
1210
1250
2796
2200
VACON1000-
ED-077-030+GAUL
77
400
56
290
1610
1250
2888
2900
VACON1000-
ED-090-030+GAUL
90
460
66
340
1610
1250
2888
2950
VACON1000-
ED-095-030+GAUL
95
490
69
350
1610
1250
2888
2975
VACON1000-
ED-100-030+GAUL
100
510
73
370
1610
1250
2888
3000
VACON1000-
ED-118-030+GAUL
118
610
86
440
1610
1250
2888
3025
VACON1000-
ED-120-030+GAUL
120
620
88
450
1610
1250
2888
3050
VACON1000-
ED-140-030+GAUL
140
720
102
530
1610
1250
2888
3100
VACON1000-
ED-180-030+GAUL
180
930
132
680
1910
1250
2888
4500
VACON1000-
ED-186-030+GAUL
186
960
136
700
1910
1250
2888
4525
VACON1000-
ED-215-030+GAUL
215
1110
157
810
1910
1250
2888
4600
VACON1000-
ED-230-030+GAUL
230
1190
168
870
3810
1400
2796
5000
VACON1000-
ED-250-030+GAUL
250
1290
183
950
4110
1400
2796
5100
VACON1000-
ED-265-030+GAUL
265
1370
194
1000
4110
1400
2796
5200
VACON1000-
ED-285-030+GAUL
285
1480
209
1080
4110
1400
2796
5300
VACON1000-
ED-305-030+GAUL
305
1580
223
1150
4110
1400
2796
5500
VACON1000-
ED-325-030+GAUL
325
1680
238
1230
4110
1400
2796
5600
VACON1000-
ED-350-030+GAUL
350
1810
256
1330
4110
1400
2796
5800
VACON1000-
ED-378-030+GAUL
378
1960
277
1430
4710
1400
2796
6450
AQ363633621020en-000201 / 172F3117 | 121Danfoss A/S © 2021.06
