Danfoss VACON 1000 User Manual

AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-408-030+GAUL
408
2120
299
1550
4710
1400
2796
6750
VACON1000-
ED-438-030+GAUL
438
2270
321
1660
4710
1400
2796
6950
VACON1000-
ED-475-030+GAUL
475
2460
348
1800
5010
1400
2796
7500
VACON1000-
ED-515-030+GAUL
515
2670
377
1950
5010
1400
2796
7800
VACON1000-
ED-560-030+GAUL
560
2900
410
2130
5010
1400
2796
8300
VACON1000-
ED-600-030+GAUL
600
3110
440
2280
5010
1400
2796
8550
VACON1000-
ED-640-030+GAUL
640
3320
469
2430
5010
1400
2796
8850
VACON1000-
ED-680-033+GAUL
680
3530
498
2580
5010
1400
2796
9350
Table 24: Nominal Voltage 3300 V, 18-pulse, 3 Power Cells per Phase, 60 Hz
AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-036-033+GAUL
36
200
26
140
1210
1250
2796
2200
VACON1000-
ED-040-033+GAUL
70
400
51
290
1210
1250
2796
2225
VACON1000-
ED-050-033+GAUL
50
280
36
200
1210
1250
2796
2250
VACON1000-
ED-061-033+GAUL
61
340
44
250
1210
1250
2796
2275
VACON1000-
ED-070-033+GAUL
70
400
51
290
1210
1250
2796
2300
VACON1000-
ED-077-033+GAUL
77
440
56
320
1610
1250
2888
3000
VACON1000-
ED-090-033+GAUL
90
510
66
370
1610
1250
2888
3050
VACON1000-
ED-095-033+GAUL
95
540
69
390
1610
1250
2888
3075
VACON1000-
ED-100-033+GAUL
100
570
73
410
1610
1250
2888
3100
AQ363633621020en-000201 / 172F3117122 | Danfoss A/S © 2021.06
Specifications
VACON® 1000
Operating Guide
