Danfoss VACON 1000

AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-118-033+GAUL
118
670
86
490
1610
1250
2888
3125
VACON1000-
ED-120-033+GAUL
120
680
88
500
1610
1250
2888
3150
VACON1000-
ED-140-033+GAUL
140
800
102
580
1610
1250
2888
3200
VACON1000-
ED-180-033+GAUL
180
1020
132
750
1910
1250
2888
4600
VACON1000-
ED-186-033+GAUL
186
1060
136
770
1910
1250
2888
4625
VACON1000-
ED-215-033+GAUL
215
1220
157
890
1910
1250
2888
4700
VACON1000-
ED-230-033+GAUL
230
1310
168
960
4110
1400
2796
5100
VACON1000-
ED-250-033+GAUL
250
1420
183
1040
4110
1400
2796
5300
VACON1000-
ED-265-033+GAUL
265
1510
194
1100
4110
1400
2796
5400
VACON1000-
ED-285-033+GAUL
285
1620
209
1190
4110
1400
2796
5500
VACON1000-
ED-305-033+GAUL
305
1740
223
1270
4110
1400
2796
5800
VACON1000-
ED-325-033+GAUL
325
1850
238
1360
4110
1400
2796
5900
VACON1000-
ED-350-033+GAUL
350
2000
256
1460
4110
1400
2796
6100
VACON1000-
ED-378-033+GAUL
378
2160
277
1580
4710
1400
2796
6750
VACON1000-
ED-408-033+GAUL
408
2330
299
1700
4710
1400
2796
7150
VACON1000-
ED-438-033+GAUL
438
2500
321
1830
5010
1400
2796
7450
VACON1000-
ED-475-033+GAUL
475
2710
348
1980
5010
1400
2796
7900
VACON1000-
ED-515-033+GAUL
515
2940
377
2150
5010
1400
2796
8200
VACON1000-
ED-560-033+GAUL
560
3200
410
2340
5010
1400
2796
8700
