Danfoss VLT AAF006 - 6.4.2 0-1* Set-up Operations

0-10 Active Set-up
Option: Function:
Select the set-up to control the filter functions.
[0] Factory
setup
Cannot be changed. It contains the factory
data set, and can be used as a data source
when returning the other set-ups to a known
state.
[1] * Set-up 1
[1] Set-up 1to [4] Set-up 4are the 4 separate
parameter set-ups within which all parameters
can be programmed.
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Multi Set-
up
Remote set-up selections using digital inputs
and the serial communication port. This set-up
uses the settings from parameter 0-12 This Set-
up Linked to. Stop the filter before making
changes to open- and closed loop functions
Use parameter 0-51 Set-up Copy to copy a set-up to one or
all other set-ups. Stop the filter before switching between
set-ups where parameters marked not changeable during
operation have different values. To avoid conflicting
settings of the same parameter within 2 different set-ups,
link the set-ups together using parameter 0-12 This Set-up
Linked to. Parameters which are not changeable during
operation are marked FALSE in the parameter lists in
chapter 6.12 Parameter Lists.
0-11 Edit Set-up
Option: Function:
Select the set-up to be edited (i.e.
programmed) during operation; either the
active set-up or one of the inactive set-ups.
[0] Factory
setup
Cannot be edited but it is useful as a data
source to return the other set-ups to a known
state.
[1] * Set-up 1
[1] Set-up 1to [4] Set-up 4 can be edited freely
during operation, independently of the active
set-up.
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Active Set-
up
Can also be edited during operation. Edit the
selected set-up from a range of sources: LCP,
FC, RS485, FC, USB, or up to 5 Fieldbus sites.
0-12 This Set-up Linked to
Option: Function:
To enable conflict-free changes from one set-up
to another during operation, link set-ups
containing parameters that are not changeable
during operation. The link ensures synchro-
nising of the not changeable during operation
0-12 This Set-up Linked to
Option: Function:
parameter values when moving from one set-
up to another during operation. Not changeable
during operation parameters can be identified
by the label FALSE in the parameter lists in
chapter 6.12 Parameter Lists.
Parameter 0-12 This Set-up Linked to is used by
[9] Multi set-up in parameter 0-10 Active Set-up.
[9] Multi set-up is used to move from one set-up
to another during operation (i.e. while the filter
is running).
Example:
Use [9] Multi set-up to shift from Set-up 1 to
Set-up 2 while the unit is running. Programme
in Set-up 1 first, then ensure that Set-up 1 and
Set-up 2 are synchronised (or linked). Synchro-
nisation can be performed in 2 ways:
1.
Change the edit set-up to [2] Set-up
2in parameter 0-11 Edit Set-up and set
parameter 0-12 This Set-up Linked to to
[1] Set-up 1. This starts the linking
(synchronising) process.
130BP075.10
0-12 This Set-up Linked to
0 RPM
0.00A 1(1)
Set-up Handling 0-1*
[1]
Setup 1
Illustration 6.6 Synchronisation Method 1
OR
1. While still in Set-up 1, copy Set-up 1
to Set-up 2. Then set
parameter 0-12 This Set-up Linked to to
[2] Set-up 2. This starts the linking
process.
130BP076.10
0-12 This Set-up Linked to
0 RPM
0.00A 1(1)
Set-up Handling
0-1*
[2] Setup 2
Illustration 6.7 Synchronisation Method 2
After the link is complete,
parameter 0-13 Readout: Linked Set-ups reads
{1,2} to indicate that all not changeable during
operation parameters are now the same in Set-
up 1 and Set-up 2. If there are changes to a not
changeable during operation parameter, in Set-
up 2, they are also changed automatically in
Applications and Basic Prog...
