8-13 Configurable Status Word STW
Option: Function:
This parameter enables configuration of bit 12 – 15 in the status
word.
[0] No function
[1]
*
Profile default Function corresponds to the profile default selected in par. 8-10.
[2] Alarm 68 only Only set in case of an Alarm 68.
[3] Trip except Alarm 68 Set in case of a trip, except if the trip is executed by an Alarm
68.
[16] T37 DI status The bit indicates the status of terminal 37.
“0” indicates T37 is low (safe stop)
“1” indicates T37 is high (normal)
2.9.4. 8-3* FC Port Settings
Parameters for configuring the FC Port.
8-30 Protocol
Option: Function:
Protocol selection for the integrated FC (standard) Port (RS485)
on the control card.
[0]
*
FC Communication according to the FC Protocol as described in
RS-485 Installation and Set-up .
[1] FC MC Same as
FC [0] but to be used when downloading SW to the
frequency converter or uploading dll file (covering information
regarding parameters available in the frequency converter and
their inter-dependencies) to Motion Control Tool MCT10.
[2] Modbus RTU Communication according to the Modbus RTU protocol.
[9] FC option
8-31 Address
Range: Function:
1
*
[1 - 126 ] Enter the address for the FC (standard) port.
Valid range: 1 - 126.
8-32 FC Port Baud Rate
Option: Function:
Baud rate selection depends on Protocol selection in par. 8-30.
[0] 2400 Baud
[1] 4800 Baud
[2]
*
9600 Baud
[3] 19200 Baud
[4] 38400 Baud
2. Parameter Description VLT
®
AQUA Drive Programming Guide
110 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
