Option
Name
Description
[28]
Logic rule 2
Use the result of logic rule 2.
[29]
Logic rule 3
Use the result of logic rule 3.
[33]
Digital input DI18
Use the result of digital input 18.
[34]
Digital input DI19
Use the result of digital input 19.
[35]
Digital input DI27
Use the result of digital input 27.
[36]
Digital input DI29
N O T I C E
This option is only available in FC 302.
Use the result of digital input 29.
[37]
Digital input DI32
Use the result of digital input 32.
[38]
Digital input DI33
Use the result of digital input 33.
[39]
Start command
A start command is issued. This is the default option.
[40]
Drive stopped
A stop command (jog, stop, quick stop, coast) is issued - and not from SLC itself.
[41]
Reset trip
A reset is issued.
[42]
Auto-reset trip
An auto reset is performed.
[43]
OK key
[OK] is pressed. Only available on the graphical LCP.
[44]
Reset key
[Reset] is pressed. Only available on the graphical LCP.
[45]
Left key
[◃] is pressed. Only available on the graphical LCP.
[46]
Right key
[▹] is pressed. Only available on the graphical LCP.
[47]
Up key
[▵] is pressed. Only available on the graphical LCP.
[48]
Down key
[▿] is pressed. Only available on the graphical LCP.
[50]
Comparator 4
Use the result of comparator 4.
[51]
Comparator 5
Use the result of comparator 5.
[60]
Logic rule 4
Use the result of logic rule 4.
[61]
Logic rule 5
Use the result of logic rule 5.
[76]
Digital input X30/2
Use the value of X30/2 (VLT® General Purpose I/O MCB 101).
[77]
Digital input X30/3
Use the value of X30/3 (VLT® General Purpose I/O MCB 101).
[78]
Digital input X30/4
Use the value of X30/4 (VLT® General Purpose I/O MCB 101).
[79]
Digital input X46/1
Use the value of X46/1 (VLT® Extended Relay Card MCB 113).
[80]
Digital input X46/3
Use the value of X46/3 (VLT® Extended Relay Card MCB 113).
[81]
Digital input X46/5
Use the value of X46/5 (VLT® Extended Relay Card MCB 113).
[82]
Digital input X46/7
Use the value of X46/7 (VLT® Extended Relay Card MCB 113).
[83]
Digital input X46/9
Use the value of X46/9 (VLT® Extended Relay Card MCB 113).
AU275636650261en-000101 / 130R0334 | 375Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
