3.1.3 Ordering Form Type Code
It is possible to design a VLT Low Harmonic Drive according to the application requirements by using the ordering number
system.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 - - 30
F C - X 0 2 P X X 0 T 5 E 2 1 N 2 X G C X X X S X X X X X . . X
Table 3.1
Product groups
1-3
Frequency converter series
4-6
Power rating
8-10
Phases
11
Mains Voltage
12
Enclosure
13-15
Enclosure type
Enclosure class
Control supply voltage
Hardware configuration
RFI filter
16-17
Brake
18
Display (LCP)
19
Coating PCB
20
Mains option
21
Adaptation A
22
Adaptation B
23
Software release
24-27
Software language
28
A options
29-30
B options
31-32
C0 options, MCO
33-34
C1 options
35
C option software
36-37
D options
38-39
Table 3.2
To order a VLT Low Harmonic Drive, type the letter “N” in
position 16 of the type code string. Not all choices/options
are available for each frequency converter variant. To verify
if the appropriate version is available, consult the Drive
Configurator on the Internet. For more information on the
options available, see the Design Guide.
