[56] DigiPot
Decrease
DECREASE signal to the Digital Potenti-
ometer function described in parameter
group 3-9*
[57] DigiPot Clear Clears the Digital Potentiometer reference
described in parameter group 3-9*
[60] Counter A (Terminal 29 or 33 only) Input for
increment counting in the SLC counter.
[61] Counter A (Terminal 29 or 33 only) Input for
decrement counting in the SLC counter.
[62] Reset
Counter A
Input for reset of counter A.
[63] Counter B (Terminal 29 or 33 only) Input for
increment counting in the SLC counter.
[64] Counter B (Terminal 29 or 33 only) Input for
decrement counting in the SLC counter.
[65] Reset
Counter B
Input for reset of counter B.
[70] Mech. Brake
Feedback
Brake feedback for hoisting applications:
Set 1-01 Motor Control Principle to [3] flux
w/ motor feedback; set 1-72 Start Function to
[6] Hoist mech brake Ref.
[71] Mech. Brake
Feedback inv.
Inverted brake feedback for hoisting
applications
[72] PID error
inverse
When enabled, it inverts the resulting error
from the process PID controller. Available
only if "Configuration Mode" is set to
"Surface Winder", "Extended PID Speed OL"
or "Extended PID Speed CL".
[73] PID reset I-
part
When enabled, resets the I-part of the
Process PID controller. Equivalent to
7-40 Process PID I-part Reset. Available only
if "Configuration Mode" is set to "Surface
Winder", "Extended PID Speed OL" or
"Extended PID Speed CL".
[74] PID enable When enabled, enables the extended
process PID controller. Equivalent to
7-50 Process PID Extended PID. Available only
if "Configuration Mode" is set "Extended
PID Speed OL" or "Extended PID Speed CL".
[80] PTC Card 1 All Digital Inputs can be set to PTC Card 1
[80]. However, only one Digital Input must
be set to this choice.
[91] Profidrive
OFF2
The functionality is the same as the
according control word bit of the Profibus/
Profinet option.
[92] Profidrive
OFF3
The functionality is the same as the
according control word bit of the Profibus/
Profinet option.
[98] Start edge
triggered
Edge triggered start command. Keeps the
start command alive, even if the input is
going back to low - can be used for a start
push-button.
[100] Safe Option
Reset
6.1.6 5-3* Digital Outputs
The 2 solid-state digital outputs are common for terminals
27 and 29. Set the I/O function for terminal 27 in
5-01 Terminal 27 Mode, and set the I/O function for
terminal 29 in 5-02 Terminal 29 Mode.
NOTE
These parameters cannot be adjusted while the motor is
running.
[0] No operation Default for all digital outputs and relay
outputs
[1] Control ready The control card is ready. E.g.: Feedback
from a frequency converter where the
control is supplied by an external 24 V
(MCB 107) and the main power to the
unit is not detected.
[2] Drive ready The frequency converter is ready for
operation and applies a supply signal on
the control board.
[3] Drive ready /
remote control
The frequency converter is ready for
operation and is in [Auto on] mode.
[4] Enable / no
warning
Ready for operation. No start or stop
command is been given (start/disable).
No warnings are active.
[5] VLT running Motor is running and shaft torque
present.
[6] Running / no
warning
Output speed is higher than the speed
set in 1-81 Min Speed for Function at Stop
[RPM]. The motor is running and there
are no warnings.
[7] Run in range /
no warning
Motor is running within the programmed
current and speed ranges set in
4-50 Warning Current Low to 4-53 Warning
Speed High. There are no warnings.
[8] Run on
reference / no
warning
Motor runs at reference speed. No
warnings.
[9] Alarm An alarm activates the output. There are
no warnings.
[10] Alarm or
warning
An alarm or a warning activates the
output.
[11] At torque limit
The torque limit set in 4-16 Torque Limit
Motor Mode or 4-17 Torque Limit
Generator Mode has been exceeded.
[12] Out of current
range
The motor current is outside the range
set in 4-18 Current Limit.
[13] Below current,
low
Motor current is lower than set in
4-50 Warning Current Low.
[14] Above current,
high
Motor current is higher than set in
4-51 Warning Current High.
[15] Out of range Output frequency is outside the
frequency range set in 4-52 Warning
Speed Low and 4-53 Warning Speed High.
