6.3.2 1-** Load/Motor
Par.
No. #
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
1-0* General Settings
1-00 Configuration Mode null All set-ups TRUE - Uint8
1-01 Motor Control Principle null All set-ups FALSE - Uint8
1-02 Flux Motor Feedback Source [1] 24V encoder All set-ups FALSE - Uint8
1-03 Torque Characteristics [0] Constant torque All set-ups x TRUE - Uint8
1-04 Overload Mode [0] High torque All set-ups FALSE - Uint8
1-05 Local Mode Configuration [2] As mode par 1-00 All set-ups TRUE - Uint8
1-06 Clockwise Direction [0] Normal All set-ups FALSE - Uint8
1-1* Motor Selection
1-10 Motor Construction [0] Asynchron All set-ups FALSE - Uint8
1-2* Motor Data
1-20 Motor Power [kW] App.Dependent All set-ups FALSE 1 Uint32
1-21 Motor Power [HP] App.Dependent All set-ups FALSE -2 Uint32
1-22 Motor Voltage App.Dependent All set-ups FALSE 0 Uint16
1-23 Motor Frequency App.Dependent All set-ups FALSE 0 Uint16
1-24 Motor Current App.Dependent All set-ups FALSE -2 Uint32
1-25 Motor Nominal Speed App.Dependent All set-ups FALSE 67 Uint16
1-26 Motor Cont. Rated Torque App.Dependent All set-ups FALSE -1 Uint32
1-29 Automatic Motor Adaptation (AMA) [0] Off All set-ups FALSE - Uint8
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs) App.Dependent All set-ups FALSE -4 Uint32
1-31 Rotor Resistance (Rr) App.Dependent All set-ups FALSE -4 Uint32
1-33 Stator Leakage Reactance (X1) App.Dependent All set-ups FALSE -4 Uint32
1-34 Rotor Leakage Reactance (X2) App.Dependent All set-ups FALSE -4 Uint32
1-35 Main Reactance (Xh) App.Dependent All set-ups FALSE -4 Uint32
1-36 Iron Loss Resistance (Rfe) App.Dependent All set-ups FALSE -3 Uint32
1-37 d-axis Inductance (Ld) App.Dependent All set-ups x FALSE -4 Int32
1-39 Motor Poles App.Dependent All set-ups FALSE 0 Uint8
1-40 Back EMF at 1000 RPM App.Dependent All set-ups x FALSE 0 Uint16
1-41 Motor Angle Offset 0 N/A All set-ups FALSE 0 Int16
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed 100 % All set-ups TRUE 0 Uint16
1-51 Min Speed Normal Magnetising [RPM] App.Dependent All set-ups TRUE 67 Uint16
1-52 Min Speed Normal Magnetising [Hz] App.Dependent All set-ups TRUE -1 Uint16
1-53 Model Shift Frequency App.Dependent All set-ups x FALSE -1 Uint16
1-54 Voltage reduction in fieldweakening 0 V All set-ups FALSE 0 Uint8
1-55 U/f Characteristic - U App.Dependent All set-ups TRUE -1 Uint16
1-56 U/f Characteristic - F App.Dependent All set-ups TRUE -1 Uint16
1-58 Flystart Test Pulses Current 30 % All set-ups FALSE 0 Uint16
1-59 Flystart Test Pulses Frequency 200 % All set-ups FALSE 0 Uint16
Table 6.16
How to Programme the Low Ha... VLT Automation Low Harmonic Drive Operating Instructions
92 MG34O202 - VLT
®
is a registered Danfoss trademark
