Danfoss VLT AutomationDrive FC 361 Programming Guide

8-43 PCD Read Conguration
Range: Function:
[3422] PCD 2 Read
from MCO
[3423] PCD 3 Read
from MCO
[3424] PCD 4 Read
from MCO
[3425] PCD 5 Read
from MCO
[3426] PCD 6 Read
from MCO
[3427] PCD 7 Read
from MCO
[3428] PCD 8 Read
from MCO
[3429] PCD 9 Read
from MCO
[3430] PCD 10 Read
from MCO
4.9.5 8-5* Digital/Bus
Parameters for conguring the control word merging.
NOTICE
These parameters are active only when
parameter 8-01 Control Site is set to [0] Digital and control
word.
8-50 Coasting Select
Select the trigger for the coasting function.
Option: Function:
[0] Digital input A digital input triggers the coasting
function.
[1] Bus A serial communication port or the
eldbus triggers the coasting
function.
[2] Logic AND The eldbus/serial communication
port and a digital input trigger the
coasting function.
[3] * Logic OR The eldbus/serial communication
port or a digital input triggers the
coasting function.
8-51 Quick Stop Select
Select the trigger for the quick stop function.
Option: Function:
[0] Digital input
[1] Bus
[2] Logic AND
[3] * Logic OR
8-52 DC Brake Select
Select control of the DC brake via the terminals (digital input)
and/or via the eldbus.
Option: Function:
NOTICE
When parameter 1-10 Motor
Construction is set to [1] PM
non-salient SPM, only selection
[0] Digital input is available.
[0] Digital input Activate a start command via a
digital input.
[1] Bus Activate a start command via the
serial communication port or
eldbus option.
[2] Logic AND Activate a start command via the
eldbus/serial communication port
and also via 1 of the digital inputs.
[3] Logic OR Activate a start command via the
eldbus/serial communication port
or via 1 of the digital inputs.
8-53 Start Select
Select the trigger for the start function.
Option: Function:
[0] Digital input A digital input triggers the start
function.
[1] Bus A serial communication port or the
eldbus triggers the start function.
[2] Logic AND The eldbus/serial communication
port and a digital input trigger the
start function.
[3] * Logic OR The eldbus/serial communication
port or a digital input triggers the
start function.
8-54 Reversing Select
Select the trigger for the reversing function.
Option: Function:
[0] Digital input A digital input triggers the
reversing function.
[1] Bus A serial communication port or the
eldbus triggers the reversing
function.
[2] Logic AND The eldbus/serial communication
port and a digital input trigger the
reversing function.
[3] Logic OR The eldbus/serial communication
port or a digital input triggers the
reversing function.
Parameter Descriptions VLT® AutomationDrive FC 361
102 Danfoss A/S © 03/2019 All rights reserved. MG06J202
44
