Danfoss VLT AutomationDrive FC 361 Programming Guide

4.12.1 13-0* SLC Settings
Use the SLC settings to activate, deactivate, and reset the
smart logic control sequence. The logic functions and
comparators are always running in the background, which
opens for separate control of digital inputs and outputs.
13-00 SL Controller Mode
Option: Function:
[0] O Disables the smart logic controller.
[1] On Enables the smart logic controller.
13-01 Start Event
Select the boolean (true or false) input to activate smart logic
control.
Option: Function:
[0] False Select the boolean (true or false)
input to activate smart logic
control.
Enters the xed value - false.
[1] True Enters the xed value - true.
[2] Running The motor runs.
[3] In range The motor runs within the
programmed current and speed
ranges set in
parameter 4-50 Warning Current Low
to parameter 4-53 Warning Speed
High.
[4] On reference The motor runs on reference.
[5] Torque limit The torque limit set in
parameter 4-16 Torque Limit Motor
Mode or parameter 4-17 Torque Limit
Generator Mode is exceeded.
[6] Current Limit The motor current limit set in
parameter 4-18 Current Limit is
exceeded.
[7] Out of current
range
The motor current is outside the
range set in parameter 4-18 Current
Limit.
[8] Below I low The motor current is lower than set
in parameter 4-50 Warning Current
Low.
[9] Above I high The motor current is higher than
set in parameter 4-51 Warning
Current High.
[10] Out of speed
range
The speed is outside the range set
in parameter 4-52 Warning Speed
Low and parameter 4-53 Warning
Speed High.
[11] Below speed
low
The output speed is lower than the
setting in parameter 4-52 Warning
Speed Low.
13-01 Start Event
Select the boolean (true or false) input to activate smart logic
control.
Option: Function:
[12] Above speed
high
The output speed is higher than
the setting in
parameter 4-53 Warning Speed High.
[13] Out of feedb.
range
The feedback is outside the range
set in parameter 4-56 Warning
Feedback Low and
parameter 4-57 Warning Feedback
High.
[14] Below feedb.
low
The feedback is below the limit set
in parameter 4-56 Warning Feedback
Low.
[15] Above feedb.
high
The feedback is above the limit set
in parameter 4-57 Warning Feedback
High.
[16] Thermal
warning
The thermal warning turns on when
the temperature exceeds the limit
in the motor, the frequency
converter, the brake resistor, or the
thermistor.
[17] Mains out of
range
The mains voltage is outside the
specied voltage range.
[18] Reversing The output is high when the
frequency converter is running
counterclockwise (the logical
product of the status bits running
AND reverse).
[19] Warning A warning is active.
[20] Alarm (trip) A (trip) alarm is active.
[21] Alarm (trip
lock)
A (trip lock) alarm is active.
[22] Comparator 0 Use the result of comparator 0.
[23] Comparator 1 Use the result of comparator 1.
[24] Comparator 2 Use the result of comparator 2.
[25] Comparator 3 Use the result of comparator 3.
[26] Logic rule 0 Use the result of logic rule 0.
[27] Logic rule 1 Use the result of logic rule 1.
[28] Logic rule 2 Use the result of logic rule 2.
[29] Logic rule 3 Use the result of logic rule 3.
[33] Digital input
DI18
Use the result of digital input 18.
[34] Digital input
DI19
Use the result of digital input 19.
[35] Digital input
DI27
Use the result of digital input 27.
[36] Digital input
DI29
Use the result of digital input 29.
Parameter Descriptions Programming Guide
MG06J202 Danfoss A/S © 03/2019 All rights reserved. 117
4 4
