Danfoss VLT AutomationDrive FC 361 Programming Guide

13-02 Stop Event
Select the boolean (true or false) input to deactivate smart logic
control.
Option: Function:
[39] Start
command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key [OK] is pressed. Only available on
the graphical LCP.
[44] Reset key [Reset] is pressed. Only available on
the graphical LCP.
[45] Left key
[◄] is pressed. Only available on the
graphical LCP.
[46] Right key
[►] is pressed. Only available on the
graphical LCP.
[47] Up key
[
▲
] is pressed. Only available on the
graphical LCP.
[48] Down key
[
▼
] is pressed. Only available on the
graphical LCP.
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3 Smart logic controller timer 3 is
timed out.
[71] SL Time-out 4 Smart logic controller timer 4 is
timed out.
[72] SL Time-out 5 Smart logic controller timer 5 is
timed out.
[73] SL Time-out 6 Smart logic controller timer 6 is
timed out.
[74] SL Time-out 7 Smart logic controller timer 7 is
timed out.
[75] Start
command
given
[76] Digital input
x30/2
[77] Digital input
x30/3
[78] Digital input
x30/4
[83] Broken Belt
[102] Relay 1
[103] Relay 2
13-03 Reset SLC
Option: Function:
[0] * Do not reset
SLC
Retain programmed settings in
parameter group 13-** Smart Logic.
[1] Reset SLC Reset all parameters in parameter
group 13-** Smart Logic to default
settings.
4.12.2 13-1* Comparators
Comparators are used for comparing continuous variables
(that is output frequency, output current, analog input, and
so on) to xed preset values.
Par. 13-11
Comparator Operator
=
TRUE longer than.
. . .
. . .
Par. 13-10
Comparator Operand
Par. 13-12
Comparator Value
130BB672.10
Illustration 4.38 Comparators
There are digital values that are compared to xed time
values. See the explanation in parameter 13-10 Comparator
Operand. Comparators are evaluated once in each scan
interval. Use the result (true or false) directly. All
parameters in this parameter group are array parameters
with index 0–5. Select index 0 to program comparator 0,
select index 1 to program comparator 1, and so on.
13-10 Comparator Operand
Option: Function:
Options [1] Reference % to [31]
Counter B are variables which are
compared based on their values.
Options [50] FALSE to [186] Drive in
auto mode are digital values (true/
false) where the comparison is
based on the amount of time
during which they are set to true or
false. See
parameter 13-11 Comparator
Operator.
Select the variable to be monitored
by the comparator.
[0] DISABLED The comparator is disabled.
[1] Reference % The resulting remote reference in
percent.
[2] Feedback % [RPM] or [Hz], as set in
parameter 0-02 Motor Speed Unit.
Parameter Descriptions Programming Guide
MG06J202 Danfoss A/S © 03/2019 All rights reserved. 119
4 4
