13-42 Logic Rule Boolean 2
Option: Function:
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[37] Digital input
DI32
[38] Digital input
DI33
[39] Start
command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key [OK] is pressed. Only available on
the graphical LCP.
[44] Reset key [Reset] is pressed. Only available on
the graphical LCP.
[45] Left key
[◄] is pressed. Only available on the
graphical LCP.
[46] Right key
[►] is pressed. Only available on the
graphical LCP.
[47] Up key
[
▲
] is pressed. Only available on the
graphical LCP.
[48] Down key
[
▼
] is pressed. Only available on the
graphical LCP.
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
13-43 Logic Rule Operator 2
Array [6]
Option: Function:
Select the 2
nd
logical operator to be
used on the boolean input
calculated in:
•
Parameter 13-40 Logic Rule
Boolean 1.
•
Parameter 13-41 Logic Rule
Operator 1.
•
Parameter 13-42 Logic Rule
Boolean 2.
[13-44] signies the boolean input
of parameter 13-44 Logic Rule
Boolean 3.
[13-40/13-42] signies the boolean
input calculated in:
•
Parameter 13-40 Logic Rule
Boolean 1.
•
Parameter 13-41 Logic Rule
Operator 1.
•
Parameter 13-42 Logic Rule
Boolean 2.
[0] DISABLED Select this option to ignore
parameter 13-44 Logic Rule Boolean
3.
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
