15-10 Logging Source
Option: Function:
[1647] Motor Phase
W Current
[1648] Speed Ref.
After Ramp
[RPM]
[1650] External
Reference
[1651] Pulse
Reference
[1652] Feedback[Unit]
[1657] Feedback
[RPM]
[1660] Digital Input
[1662] Analog Input
53
[1664] Analog Input
54
[1665] Analog Output
42 [mA]
[1666] Digital Output
[bin]
[1675] Analog In
X30/11
[1676] Analog In
X30/12
[1677] Analog Out
X30/8 [mA]
[1687] Bus Readout
Alarm/Warning
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status
Word
[1695] Ext. Status
Word 2
[1697] Alarm Word 3
[1698] Warning Word
3
15-11 Logging Interval
Array [4]
Range: Function:
Size
related*
[ 0.000 -
0.000 ]
Enter the interval in ms between
each sampling of the variables to
be logged.
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specied percentage of samples before the occurrence of the
trigger event (parameter 15-14 Samples Before Trigger).
Option: Function:
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current
range
[8] Below I low
[9] Above I high
[10] Out of speed
range
[11] Below speed
low
[12] Above speed
high
[13] Out of feedb.
range
[14] Below feedb.
low
[15] Above feedb.
high
[16] Thermal
warning
[17] Mains out of
range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
Parameter Descriptions VLT® AutomationDrive FC 361
140 Danfoss A/S © 03/2019 All rights reserved. MG06J202
