Danfoss VLT AutomationDrive FC 361 Programming Guide

1-04 Overload Mode [1] Normal torque All set-ups FALSE – Uint8
1-05 Local Mode Conguration [2] As mode par 1-00 All set-ups TRUE – Uint8
1-06 Clockwise Direction [0] Normal All set-ups FALSE – Uint8
1-1* Special Settings
1-10 Motor Construction [0] Asynchron All set-ups FALSE – Uint8
1-14 Damping Gain 140 % All set-ups TRUE 0 Int16
1-15 Low Speed Filter Time Const. ExpressionLimit All set-ups TRUE -2 Uint16
1-16 High Speed Filter Time Const. ExpressionLimit All set-ups TRUE -2 Uint16
1-17 Voltage lter time const. ExpressionLimit All set-ups TRUE -3 Uint16
1-18 Min. Current at No Load 0 % All set-ups TRUE 0 Uint16
1-2* Motor Data
1-20 Motor Power [kW] ExpressionLimit All set-ups FALSE 1 Uint32
1-22 Motor Voltage ExpressionLimit All set-ups FALSE 0 Uint16
1-23 Motor Frequency ExpressionLimit All set-ups FALSE 0 Uint16
1-24 Motor Current ExpressionLimit All set-ups FALSE -2 Uint32
1-25 Motor Nominal Speed ExpressionLimit All set-ups FALSE 67 Uint16
1-26 Motor Cont. Rated Torque ExpressionLimit All set-ups FALSE -1 Uint32
1-29 Automatic Motor Adaptation (AMA) [0] O All set-ups FALSE – Uint8
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs) ExpressionLimit All set-ups FALSE -4 Uint32
1-31 Rotor Resistance (Rr) ExpressionLimit All set-ups FALSE -4 Uint32
1-33 Stator Leakage Reactance (X1) ExpressionLimit All set-ups FALSE -4 Uint32
1-34 Rotor Leakage Reactance (X2) ExpressionLimit All set-ups FALSE -4 Uint32
1-35 Main Reactance (Xh) ExpressionLimit All set-ups FALSE -4 Uint32
1-36 Iron Loss Resistance (Rfe) ExpressionLimit All set-ups FALSE -3 Uint32
1-37 d-axis Inductance (Ld) ExpressionLimit All set-ups FALSE -3 Int32
1-38 q-axis Inductance (Lq) ExpressionLimit All set-ups FALSE -3 Int32
1-39 Motor Poles ExpressionLimit All set-ups FALSE 0 Uint8
1-40 Back EMF at 1000 RPM ExpressionLimit All set-ups FALSE 0 Uint16
1-41 Motor Angle Oset 0 N/A All set-ups TRUE 0 Int16
1-46 Position Detection Gain 100 % All set-ups TRUE 0 Uint16
1-47 Torque Calibration ExpressionLimit All set-ups TRUE – Uint8
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed 100 % All set-ups TRUE 0 Uint16
1-51 Min Speed Normal Magnetising [RPM] ExpressionLimit All set-ups TRUE 0 Uint16
1-52 Min Speed Normal Magnetising [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-55 U/f Characteristic - U ExpressionLimit All set-ups TRUE 0 Uint16
1-56 U/f Characteristic - F ExpressionLimit All set-ups TRUE 0 Uint16
1-58 Flying Start Test Pulses Current ExpressionLimit All set-ups FALSE 0 Uint16
1-59 Flying Start Test Pulses Frequency ExpressionLimit All set-ups FALSE 0 Uint16
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation 100 % All set-ups TRUE 0 Int16
1-61 High Speed Load Compensation 100 % All set-ups TRUE 0 Int16
1-62 Slip Compensation ExpressionLimit All set-ups TRUE 0 Int16
1-63 Slip Compensation Time Constant ExpressionLimit All set-ups TRUE -2 Uint16
1-64 Resonance Damping ExpressionLimit All set-ups TRUE 0 Uint16
1-65 Resonance Damping Time Constant 5 ms All set-ups TRUE -3 Uint8
1-66 Min. Current at Low Speed ExpressionLimit All set-ups TRUE 0 Uint32
1-7* Start Adjustments
1-70 Start Mode [0] Rotor Detection All set-ups TRUE – Uint8
1-71 Start Delay 0 s All set-ups TRUE -1 Uint8
1-72 Start Function [2] Coast/delay time All set-ups TRUE – Uint8
1-73 Flying Start ExpressionLimit All set-ups FALSE – Uint8
1-74 Start Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
Parameter Lists Programming Guide
MG06J202 Danfoss A/S © 03/2019 All rights reserved. 161
5 5
