Danfoss VLT AutomationDrive FC 361 Programming Guide

1-75 Start Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-76 Start Current 0 A All set-ups TRUE -2 Uint32
1-77 Compressor Start Max Speed [RPM] ExpressionLimit All set-ups TRUE – Uint16
1-78 Compressor Start Max Speed [Hz] ExpressionLimit All set-ups TRUE – Uint16
1-79 Compressor Start Max Time to Trip 5 s All set-ups TRUE 0 Uint8
1-8* Stop Adjustments
1-80 Function at Stop [0] Coast All set-ups TRUE – Uint8
1-81 Min Speed for Function at Stop [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-82 Min Speed for Function at Stop [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-9* Motor Temperature
1-90 Motor Thermal Protection ExpressionLimit All set-ups TRUE – Uint8
1-91 Motor External Fan ExpressionLimit All set-ups TRUE – Uint8
1-93 Thermistor Resource [0] None All set-ups TRUE – Uint8
5.2.3 2-** Brakes
Param
eter
numb
er
Parameter description Default value 4 set-up Change
during
operation
Conversion
index
Type
2-0* DC-Brake
2-00 DC Hold Current 50 % All set-ups TRUE 0 Uint8
2-01 DC Brake Current 50 % All set-ups TRUE 0 Uint16
2-02 DC Braking Time 10 s All set-ups TRUE -1 Uint16
2-03 DC Brake Cut In Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
2-04 DC Brake Cut In Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
2-06 Parking Current 50 % All set-ups TRUE 0 Uint16
2-07 Parking Time 3 s All set-ups TRUE -1 Uint16
2-1* Brake Energy Funct.
2-10 Brake Function ExpressionLimit All set-ups TRUE – Uint8
2-16 AC brake Max. Current 100 % All set-ups TRUE -1 Uint32
2-17 Over-voltage Control [0] Disabled All set-ups TRUE – Uint8
2-19 Over-voltage Gain 100 % All set-ups TRUE 0 Uint16
5.2.4 3-** Reference / Ramps
Param
eter
numb
er
Parameter description Default value 4 set-up Change
during
operation
Conversion
index
Type
3-0* Reference Limits
3-00 Reference Range ExpressionLimit All set-ups TRUE – Uint8
3-01 Reference/Feedback Unit ExpressionLimit All set-ups TRUE – Uint8
3-02 Minimum Reference ExpressionLimit All set-ups TRUE -3 Int32
3-03 Maximum Reference ExpressionLimit All set-ups TRUE -3 Int32
3-04 Reference Function [0] Sum All set-ups TRUE – Uint8
3-1* References
3-10 Preset Reference 0 % All set-ups TRUE -2 Int16
3-11 Jog Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
3-12 Catch up/slow Down Value 0 % All set-ups TRUE -2 Int16
3-13 Reference Site [0] Linked to Hand / Auto All set-ups TRUE – Uint8
3-14 Preset Relative Reference 0 % All set-ups TRUE -2 Int32
3-15 Reference Resource 1 [1] Analog Input 53 All set-ups TRUE – Uint8
3-16 Reference Resource 2 ExpressionLimit All set-ups TRUE – Uint8
Parameter Lists VLT® AutomationDrive FC 361
162 Danfoss A/S © 03/2019 All rights reserved. MG06J202
