5.2.5 4-** Limits / Warnings
Param
eter
numb
er
Parameter description Default value 4 set-up Change
during
operation
Conversion
index
Type
4-1* Motor Limits
4-10 Motor Speed Direction [2] Both directions All set-ups FALSE – Uint8
4-11 Motor Speed Low Limit [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
4-12 Motor Speed Low Limit [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
4-13 Motor Speed High Limit [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
4-14 Motor Speed High Limit [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
4-16 Torque Limit Motor Mode ExpressionLimit All set-ups TRUE -1 Uint16
4-17 Torque Limit Generator Mode 100 % All set-ups TRUE -1 Uint16
4-18 Current Limit ExpressionLimit All set-ups TRUE -1 Uint32
4-19 Max Output Frequency ExpressionLimit All set-ups FALSE -1 Uint16
4-2* Limit Factors
4-20 Torque Limit Factor Source [0] No function All set-ups TRUE – Uint8
4-21 Speed Limit Factor Source [0] No function All set-ups TRUE – Uint8
4-3* Motor Fb Monitor
4-30 Motor Feedback Loss Function ExpressionLimit All set-ups TRUE – Uint8
4-31 Motor Feedback Speed Error 300 RPM All set-ups TRUE 67 Uint16
4-32 Motor Feedback Loss Timeout ExpressionLimit All set-ups TRUE -2 Uint16
4-4* Speed Monitor
4-40 Warning Freq. Low ExpressionLimit All set-ups TRUE – Uint16
4-41 Warning Freq. High ExpressionLimit All set-ups TRUE – Uint16
4-5* Adj. Warnings
4-50 Warning Current Low 0 A All set-ups TRUE -2 Uint32
4-51 Warning Current High ImaxVLT (P1637 (16.00)) A All set-ups TRUE -2 Uint32
4-52 Warning Speed Low ExpressionLimit All set-ups TRUE 67 Uint16
4-53 Warning Speed High ExpressionLimit All set-ups TRUE 67 Uint16
4-54 Warning Reference Low -999999.999 N/A All set-ups TRUE -3 Int32
4-55 Warning Reference High 999999.999 N/A All set-ups TRUE -3 Int32
4-56 Warning Feedback Low ExpressionLimit All set-ups TRUE -3 Int32
4-57 Warning Feedback High ExpressionLimit All set-ups TRUE -3 Int32
4-58 Missing Motor Phase Function [2] Trip 1000 ms All set-ups TRUE – Uint8
4-6* Speed Bypass
4-60 Bypass Speed From [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
4-61 Bypass Speed From [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
4-62 Bypass Speed To [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
4-63 Bypass Speed To [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
5.2.6 5-** Digital In/Out
Param
eter
numb
er
Parameter description Default value 4 set-up Change
during
operation
Conversion
index
Type
5-0* Digital I/O mode
5-00 Digital I/O Mode [0] PNP All set-ups FALSE – Uint8
5-01 Terminal 27 Mode [0] Input All set-ups TRUE – Uint8
5-02 Terminal 29 Mode [0] Input All set-ups TRUE – Uint8
5-1* Digital Inputs
5-10 Terminal 18 Digital Input ExpressionLimit All set-ups TRUE – Uint8
Parameter Lists VLT® AutomationDrive FC 361
164 Danfoss A/S © 03/2019 All rights reserved. MG06J202
55
