7-03 Speed PID Integral Time
Range: Function:
Size
related*
[1.0 - 20000
ms]
Enter the speed controller integral
time, which determines the time
the internal PID control takes to
correct errors. The greater the error,
the more quickly the gain increases.
The integral time causes a delay of
the signal and therefore a
dampening eect and can be used
to eliminate steady-state speed
error. Obtain quick control through
a short integral time, though if the
integral time is too short, the
process becomes unstable. An
excessively long integral time
disables the integral action, leading
to major deviations from the
required reference, since the
process regulator takes too long to
regulate errors. This parameter is
used with [0] Speed open loop and
[1] Speed closed loop control, set in
parameter 1-00 Conguration Mode.
7-04 Speed PID Dierentiation Time
Range: Function:
Size
related*
[0 - 200 ms] Enter the speed controller dieren-
tiation time. The dierentiator does
not react to constant error. It
provides gain proportional to the
rate of change of the speed
feedback. The quicker the error
changes, the stronger the gain from
the dierentiator. The gain is
proportional with the speed at
which errors change. Setting this
parameter to 0 disables the dier-
entiator. This parameter is used
with parameter 1-00 Conguration
Mode [1] Speed closed loop control.
7-05 Speed PID Di. Gain Limit
Range: Function:
5* [1 - 20] Set a limit for the gain provided by
the dierentiator. Consider limiting
the gain at higher frequencies. For
example, set up a pure D-link at
low frequencies and a constant D-
link at higher frequencies. This
parameter is used with
parameter 1-00 Conguration Mode
[1] Speed closed loop control.
7-06 Speed PID Lowpass Filter Time
Range: Function:
Size
related*
[0.1 - 100
ms]
NOTICE
Severe ltering can be
detrimental to dynamic
performance.
This parameter is used with
parameter 1-00 Conguration
Mode [1] Speed closed loop.
Set a time constant for the speed
control low-pass lter. The low-pass
lter improves steady-state
performance and dampens
oscillations on the feedback signal.
This is an advantage if there is a
great amount of noise in the
system, see Illustration 4.34. For
example, if a time constant (τ) of
100 ms is programmed, the cut-o
frequency for the low-pass lter is
1/0.1 = 10 RAD/s, corresponding to
(10/2 x π) = 1.6 Hz. The PID
regulator only regulates a feedback
signal that varies by a frequency of
less than 1.6 Hz. If the feedback
signal varies by a higher frequency
than 1.6 Hz, the PID regulator does
not react.
Practical settings of
parameter 7-06 Speed PID Lowpass
Filter Time taken from the number
of pulses per revolutions from
encoder:
Encoder
PPR
Parameter 7-06 Speed
PID Lowpass Filter
Time
512 10 ms
1024 5 ms
2048 2 ms
4096 1 ms
Table 4.16 Speed PID Lowpass
Filter Time
Parameter Descriptions VLT® AutomationDrive FC 361
88 Danfoss A/S © 03/2019 All rights reserved. MG06J202
44
